14.6 Fuses and glands
14.6.1 According to IEC ratings
Use mains fuses of the type gL/gG conforming to IEC 269
or breakers with similar characteristics. Check the
equipment first before installing the glands.
Max. Fuse = maximum fuse value that still protects the AC
drive and upholds warranty.
NOTE: The dimensions of fuse and cable cross-
section are dependent on the application and must
be determined in accordance with local regulations.
NOTE: The dimensions of the power terminals used in
the cabinet drive models 430 to 3K0 can differ
depending on customer specification.
Table 65 Fuses, cable cross-sections and glands for VFX48 and VFX52 models
Model VFX
Nominal input
current
[A]
Maximum
value fuse
[A]
Cable glands (clamping range) *
mains / motor Brake
##**-003-54 2.2 4
M32 opening
M20 + reducer
(6–12 mm(0.24 - 0.47 in))
M25 opening
M20 + reducer
(6–12 mm(0.24 - 0.47 in))
##-004-54 3.5 4
##-006-54 5.2 6
##-008-54 6.9 10 M32 (12–20)/M32 opening
M25+reducer
(10-14 mm(0.39 - 0.55 in))
M25
(10-14 mm(0.39 - 0.55 in))
##-010-54 8.7 10
##-013-54 11.3 16
M32 (16–25)/M32 (13–18)
##-018-54 15.6 20
48-025-20 22 25 - (12 - 16 mm(0.55 - 0.63 in))
##-026-54 22 25
M32
(15–21 mm(0.59 - 0.83 in))
M25
48-030-20 26 35 - (16 - 20 mm (0.63 - 0.79 in))
##-031-54 26 35
M32
(15–21 mm(0.59 - 0.83 in))
M25
48-036-20 31 35 - (20 - 24 mm(0.79 - 0.94))
##-037-54 31 35
M40
(19–28 mm (0.75 - 1.1 in))
M32
48-045-20 38 50 - (24 - 28 mm(0.94 - 1.1 in))
##-046-54 38 50
M40
(19–28 mm (0.75 - 1.1 in))
M32
48-058-20 50 63 - (24 - 28 mm(0.94 - 1.1 in))
48-060-20 52 63 - (28 - 32 mm(1.1 - 1.26 in))
##-061-54 52 63
M50
(27 - 35 mm(1.06 - 1.38 in))
M40
(19–28 mm (0.75 - 1.1 in))
48-072-20 64 80 - (28 - 32 mm(1.1 - 1.26 in))
##-074-54 65 80
M50
(27 - 35 mm(1.06 - 1.38 in))
M40
(19–28 mm(0.75 - 1.1 in))
48-088-20 78 100 - (32 - 36 mm(1.26 - 1.42 in))
48-090-54 78 100
(Ø17-42 mm (0.67 - 1.65 in)) cable
flexible leadthrough or M50
opening.
(Ø11-32 mm(0.43 - 1.26 in)) Cable
flexible leadthrough or M40
opening.
48-105-20 91 100 (32 - 36 mm(1.26 - 1.42 in)
48-109-54 94 100
(Ø17-42 mm (0.67 - 1.65 in)) cable
flexible leadthrough or M50 opening
(Ø11-32 mm(0.43 - 1.26 in)) Cable
flexible leadthrough or M40
opening
