Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Technical Data 221
Note: For IP54 models 48/52-003 to -074 and 69-002 to -058 cable glands are optional.
* IP20/21 models are equipped with cable clamps instead of glands.
**##=VFX48 and VFX52
For data on cable connection ranges, see section 3.4.3, page 42.
48-142-20 126 160 - (40 - 44 mm (1.57 - 1.73 in)) - (36 - 40 mm(1.42 - 1.57 in))
48-146-54 126 160
(Ø17-42 mm (0.67 - 1.65 in)) cable
flexible leadthrough or M50
opening.
(Ø11-32 mm(0.43 - 1.26 in)) Cable
flexible leadthrough or M40
opening.
48-171-20 152 160 - (40 - 44 mm (1.57 - 1.73 in)) - (36 - 40 mm(1.42 - 1.57 in))
48-175-54 152 160
(Ø17-42 mm (0.67 - 1.65 in)) cable
flexible leadthrough or M50
opening.
(Ø11-32 mm(0.43 - 1.26 in)) Cable
flexible leadthrough or M40
opening.
48-205-20 178 200
- (48 - 52 mm(1.89 - 2.05 in)/
52 - 56 mm (2.05 - 2.2 in))
- (44 - 48 mm (1.73 - 1.89 in))
48-210-54 182 200
(Ø23 - 55 mm (0.9 - 2.16 in))
cable flexible leadthrough or M63
opening.
(Ø17- 42 mm (0.67 - 1.65 in))
cable flexible leadthrough or M50
opening.
48-244-20 211 250
- (48 - 52 mm (1.89 - 2.05 in)/
52 - 56 mm (2.05 - 2.2 in))
- (44 - 48 mm (1.73 - 1.89 in))
48-250-54 216 250 (Ø 23 - 55 mm (0.9 - 2.16 in))
cable flexible leadthrough or M63
opening.
(Ø 23 - 55 mm (0.9 - 2.16 in))
cable flexible leadthrough or M63
opening.
48-295-54 256 300
48-293-20 254 300
- (48 - 52 mm (1.89 - 2.05 in)/
52 - 56 mm (2.05 - 2.2 in))
- (44 - 48 mm (1.73 - 1.89 in))
48-365-20 324 355 M10 bolt for cable lugs M8 bolt for cable lugs
48-365-54 324 355
(Ø 23 - 55 mm (0.9 - 2.16 in))
cable flexible leadthrough or M63
opening.
(Ø 23 - 55 mm (0.9 - 2.16 in))
cable flexible leadthrough or M63
opening.
48-430-IP 372 400
Non-applicable Non-applicable
48-500-IP 432 500
48-590-IP 513 630
48-660-IP 574 630
48-730-IP 635 710
48-810-IP 705 800
48-885-IP 770 900
48-1010-IP 879 1000
48-1100-IP 957 1250
48-1300-IP 1131 1250
48-1460-IP 1270 1500
48-1710-IP 1488 1600
48-1820-IP 1583 2 x 900
48-2190-IP 1905 2 x 1000
48-2550-IP 2219 2 x 1250
48-2920-IP 2540 2 x 1500
Table 65 Fuses, cable cross-sections and glands for VFX48 and VFX52 models
Model VFX
Nominal input
current
[A]
Maximum
value fuse
[A]
Cable glands (clamping range) *
mains / motor Brake
