Emotron VFX 2.1 User Manual

224 Technical Data CG Drives & Automation 01-7492-01r1
14.6.2 Fuses according to NEMA
ratings
Table 67 Types and fuses
Model
VFX
Input
current
[Arms]
Mains input fuses
UL
Class J TD
(A)
Ferraz-
Shawmut
type
48-003 2.2 6 AJT6
48-004 3.5 6 AJT6
48-006 5.2 6 AJT6
48-008 6.9 10 AJT10
48-010 8.7 10 AJT10
48-013 11.3 15 AJT15
48-018 15.6 20 AJT20
48-025 21.7 25 AJT25
48-026 22 25 AJT25
48-030 26 30 AJT30
48-031 26 30 AJT30
48-036 31 35 AJT35
48-037 31 35 AJT35
48-045 39 45 AJT45
48-046 40 45 AJT45
48-058 50 60 AJT60
48-060 52 60 AJT60
48-061 52 60 AJT60
48-072 64 80 AJT80
48-074 65 80 AJT80
48-088 78 100 AJT100
48-090 78 100 AJT100
48-105 91 110 AJT110
48-109 94 110 AJT110
48-142 126 125 AJT150
48-146 126 150 AJT150
48-171 152 175 AJT175
48-175 152 175 AJT175
48-205 178 200 AJT200
48-210 182 200 AJT200
48-244 211 250 AJT250
48-250 216 250 AJT250
48-293 254 300 AJT300
48-295 256 300 AJT300
48-365 324 350 AJT350
48-430 372 400 AJT400
48-500 432 500 AJT500
48-590 513 600 AJT600
48-660 574 600 AJT600
48-730 635 700 AJT700
48-810 705 800 A4BQ800
48-885 770 800 A4BQ800
48-1010 879 1000 A4BQ1000
48-1100 957 1000 A4BQ1000
48-1300 1131 1200 A4BQ1200
48-1460 1270 1500 A4BQ1500
48-1710 1488 1600 A4BQ1600
48-1820 1583 1600 A4BQ1600
48-2190 1905 2000 A4BQ2000
48-2550 2219 2500 A4BQ2500
48-2920 2540 3000 A4BQ3000
Table 67 Types and fuses
Model
VFX
Input
current
[Arms]
Mains input fuses
UL
Class J TD
(A)
Ferraz-
Shawmut
type
