CG Drives & Automation 01-7492-01r1 187
Reset Energy [7331]
Resets the energy counter. The stored information will be
erased and a new registration period will start.
11.8 View Trip Log [800]
Main menu with parameters for viewing all the logged trip
data. In total the AC drive saves the last nine trips in the trip
memory. When a trip occurs the status menus are copied to
the trip message log and here are nine trip message logs
[810]–[890]. The trip memory refreshes on the FIFO
principle (First In, First Out). When the tenth trip occurs
the oldest trip will disappear. At every trip, the actual values
of several parameter are stored and available for
troubleshooting.
Trip message log with RTC [8x0]
Trip recorded with present Real Time Clock (RTC is
mounted in 4-line control panel) are shown with actual time
and date.
Trip Message log without RTC [8x0]
Trip recorded with no present RTC are shown with the time
of the "Run Time [731]" counter at trip occurrence.
After reset of occurred trip, the trip message will disappear
and menu [100] will be indicated.
Trip message log [810]
When a trip occurs the menu will change to menu [810].
After resetting an alarm, the menu will change and show
menu [100].
Below two examples of trip messages are shown.
Here the menu shows the date and the real time when the
trip occurred.
Fig. 148
7331 Rst Energy
Default: No
No 0
Yes 1
NOTE: After reset the setting automatically goes back
to “No”.
8x0 <Trip message>
Unit:
yy:mm:dd hh:mm:ss
(year:month:day hours:minutes:seconds)
Range: 00: 00: 00–262143: 59: 59
8x0 <Trip message>
Unit: hh:mm:ss (hours:minutes:seconds)
Range: 00: 00: 00–262143: 59: 59
810 0rpm
Over temp
2020-01-15 17:15:38
Sby Rem/Rem
