CG Drives & Automation 01-7492-01r1 Menu List 227
15. Menu List
In the download area on our website, www.cgglobal.com or www.emotron.com, you find a communication information list and
a list for noting parameter set information.
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
100
Start Window
[100]
110 1st Line Process Val 43001 168/160 4BB9 19385 UInt UInt
120 2nd Line Current 43002 168/161 4BBA 19386 UInt UInt
130 3rd Line Frequency 43003 168/162 4BBB 19387 UInt UInt
140 4th Line VSD Status 43004 168/163 4BBC 19388 UInt UInt
150 5th Line DC Voltage 43005 168/164 4BBD 19389 UInt UInt
160 6th Line IGBT Temp 43006 168/165 4BBE 19390 UInt UInt
170 View mode Normal 100 43007 168/166 4BBF 19391 UInt UInt
200
Main Setup
[200]
210
Operation
[210]
211 Language English 43011 168/170 4BC3 19395 UInt UInt
212 Select Motor M1 43012 168/171 4BC4 19396 UInt UInt
213 Drive Mode Speed 43013 168/172 4BC5 19397 UInt UInt
214 Ref control Remote 43014 168/173 4BC6 19398 UInt UInt
215 Run/Stp Ctrl Remote 43015 168/174 4BC7 19399 UInt UInt
216 Reset Ctrl Remote+Keyb 43016 168/175 4BC8 19400 UInt UInt
217
Local/Remote
key function
[217]
2171 LocRefCtrl Standard 43009 168/168 4BC1 19393 UInt UInt
2172 LocRunCtrl Standard 43010 168/169 4BC2 19394 UInt UInt
218 Lock code? 0 43018 168/177 4BCA 19402 UInt, 1=1 UInt
219 Rotation R+L 43019 168/178 4BCB 19403 UInt UInt
21A Level/Edge Level 43020 168/179 4BCC 19404 UInt UInt
21B Supply Volts Not Defined 43381 170/30 4D35 19765 UInt UInt
21C Supply Type AC Supply 43382 170/31 4D36 19766 UInt UInt
220
Motor Data
[220]
221 Motor Volts [Motor] V 43041 168/200 4BE1 19425 Long, 1=0.1V EInt
222 Motor Freq 50Hz 43060 168/219 4BF4 19444 Long, 1=0.1Hz EInt
223 Motor Power [Motor] W 43043 168/202 4BE3 19427 Long, 1=1W EInt
224 Motor Curr [Motor] A 43044 168/203 4BE4 19428 Long, 1=0.1A EInt
225 Motor Speed [Motor] rpm 43045 168/204 4BE5 19429 UInt, 1=1rpm UInt
226 Motor Poles [Motor] 43046 168/205 4BE6 19430 Long, 1=1 EInt
227 Motor Cosϕ [Motor] 43047 168/206 4BE7 19431 Long, 1=0.01 EInt
228 Motor Vent Self 43048 168/207 4BE8 19432 UInt UInt
