26 Mounting CG Drives & Automation 01-7492-01r1
2.3.3 Mounting schemes, cabinets
Emotron VFX48: Model 430 to 730 (Frame sizes H,
G2 and H2)
Emotron VFX69: Model 250 to 400 (Frame size H69)
Emotron VFX48: Model 1300 to 1460 (Frame size H4)
Emotron VFX69: Model 650 to 800 (Frame size J69)
Emotron VFX48: Model 810 to 1100 (Frame sizes G3
and H3)
Emotron VFX69: Model 430 to 595 (Frame size I69)
Emotron VFX48: Model 1710 to 1820 (Frame size H5)
Emotron VFX69: Model 905 to 995 (Frame size KA69)
600 mm (23.6 in)
2200 mm (86.6 in)
2000 mm (78,7 in)
(3.9 in)
(3.9 in)
100 mm
600 mm
(23.6 in)
100 mm
01-5301-00
(3.9 in)
100 mm
2200 mm (86.6 in)
2000 mm (78,7 in)
(3.9 in)
100 mm
600 mm
(23.6 in)
1200 mm (47.2 in)
1000 mm (39.4 in)
2000 mm (78,7 in)
(3.9 in)
(3.9 in)
100 mm
600 mm
(23.6 in)
2200 mm (86.6 in)
100 mm
01-5301-00
1600 mm (63.0 in)
2000 mm (78,7 in)
(3.9 in)
(3.9 in)
100 mm
600 mm
(23.6 in)
2200 mm (86.6 in)
100 mm
