76 Communication CG Drives & Automation 01-7492-01r1
Parameter set A contains parameters 43001 to 43899. The
parameter sets B, C and D contains the same type of
information. For example parameter 43123 in parameter set
A contain the same type of information as 44123 in
parameter set B.
9.3 Motor data
Communication information for the different motors.
M1 contains parameters 43041 to 43048. The M2, M3, and
M4 contains the same type of information. For example
parameter 43043 in motor M1 contain the same type of
information as 44043 in M2.
9.4 Start and stop commands
Set start and stop commands via serial communication.
9.5 Reference signal
When menu “Reference Control [214]” is set to “Com” the
following parameter data should be used:
9.5.1 Process value
It is also possible to send the Process value feedback
signal over a bus (e.g. from a process or temperature sensor)
for use with PID Process controller [380].
Set menu “Process Source [321]” to F(Bus). Use following
parameter data for the process value:
Example:
(See Emotron Fielbus manual for detailed information)
We would like to control the AC drive over a bus system
using the first two bytes of the Basic Control Message by
setting menu “[2661] FB Signal 1” to 49972. Further, we
also want to transmit a 16 bit signed reference and a 16 bit
process value. This is done by setting menu
“[2662] FB Signal 2” to 42905 and menu “[2663] FB Signal
3” to 42906.
Motor
Modbus/
DeviceNet
Instance
number
Profibus
Slot/
Index
Profinet IO
index
EtherCAT
and
CANopen
index
(hex)
M1
43041–
43048
168/200
to
168/207
19425 -
19432
4be1 - 4be8
M2
44041–
44048
172/180
to
174/187
20425 -
20432
4fc9 - 4fd0
M3
45041–
45048
176/160
to
176/167
21425 -
21432
53b1 - 53b8
M4
46041–
46048
180/140
to
180/147
22425 -
22432
5799 - 57a0
Modbus/DeviceNet
Instance number
Function
42901 Reset
42902
Run, active together with either
RunR or RunL to
perform start.
42903 RunR
42904 RunL
Note! Bipolar reference mode is activated if both
RunR and RunL is active.
Default 0
Range -16384 to 16384
Corresponding to -100% to 100% ref
Communication information
Modbus /DeviceNet Instance number 42905
Profibus slot /Index 168/64
EtherCAT index (hex) 4b59
Profinet IO index 19289
Fieldbus format Int
Modbus format Int
Default 0
Range -16384 to 16384
Corresponding to -100% to 100% process value
Communication information
Modbus /DeviceNet Instance number 42906
Profibus slot /Index 168/65
EtherCAT index (hex)
4b5a
Profinet IO index 19290
Fieldbus format Int
Modbus format Int
NOTE! It is possible to view the transmitted process
value in control panel menu Operation [710]. The
presented value is depending on settings in menus
“Process Min [324]” and “Process Max [325]”.
