Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Menu List 233
323 User Unit 0
43304 169/208 4CE8 19688 UInt UInt
43305 169/209 4CE9 19689 UInt UInt
43306 169/210 4CEA 19690 UInt UInt
43307 169/211 4CEB 19691 UInt UInt
43308 169/212 4CEC 19692 UInt UInt
43309 169/213 4CED 19693 UInt UInt
324 Process Min 0 43310 169/214 4CEE 19694 Long, 1=0.001 EInt
325 Process Max 0 43311 169/215 4CEF 19695 Long, 1=0.001 EInt
326 Ratio Linnear 43312 169/216 4CF0 19696 UInt UInt
327 F(Val) PrMin Min 43313 169/217 4CF1 19697 Long, 1=1 EInt
328 F(Val) PrMax Max 43314 169/218 4CF2 19698 Long, 1=1 EInt
330
Start/Stop
settings [330]
331 Acc Time 10s 43101 169/5 4C1D 19485 Long, 1=0.01s EInt
332 Dec Time 10s 43102 169/6 4C1E 19486 Long, 1=0.01s EInt
333 Acc MotPot 16s 43103 169/7 4C1F 19487 Long, 1=0.01s EInt
334 Dec MotPot 16s 43104 169/8 4C20 19488 Long, 1=0.01s EInt
335 Acc<Min Spd 10s 43105 169/9 4C21 19489 Long, 1=0.01s EInt
336 Dec<Min Spd 10s 43106 169/10 4C22 19490 Long, 1=0.01s EInt
337 Acc Rmp Linear 43107 169/11 4C23 19491 UInt UInt
338 Dec Rmp Linear 43108 169/12 4C24 19492 UInt UInt
339 Start Mode Normal DC 43109 169/13 4C25 19493 UInt UInt
33A Spinstart Off 43110 169/14 4C26 19494 UInt UInt
33B Stop Mode Decel 43111 169/15 4C27 19495 UInt UInt
33C Brk Release 0s 43112 169/16 4C28 19496 Long, 1=0.01s EInt
33D Release Spd 0rpm 43113 169/17 4C29 19497 Int, 1=1rpm Int
33E Brk Engage 0s 43114 169/18 4C2A 19498 Long, 1=0.01s EInt
33F Brk Wait 0s 43115 169/19 4C2B 19499 Long, 1=0.01s EInt
33G Vector Brake Off 43116 169/20 4C2C 19500 UInt UInt
33H Brk Fault 1s 43117 169/21 4C2D 19501 Long, 1=0.01s EInt
33I Release Trq 0% 43118 169/22 4C2E 19502 Long, 1=1% EInt
33J DC Hold [33J]
33J1 DC Hold Off 43148 169/52 4C4C 19532 UInt UInt
33J2 DC Hold Spd 10rpm 43149 169/53 4C4D 19533 UInt, 1=1rpm UInt
33J3 DC Hold Cur 30% 43150 169/54 4C4E 19534 UInt, 1=1% UInt
33K Start Vector Normal (U) 43119 169/23 4C2F 19503 UInt UInt
340 Speed [340]
341 Min Speed 0rpm 43121 169/25 4C31 19505 Int, 1=1rpm Int
342 Stp<MinSpd Off 43122 169/26 4C32 19506 Long, 1=0.01s EInt
343 Max Speed Sync speed 43123 169/27 4C33 19507 Int, 1=1rpm Int
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
