Emotron VFX 2.1 User Manual

234 Menu List CG Drives & Automation 01-7492-01r1
344 SkipSpd 1 Lo 0rpm 43124 169/28 4C34 19508 Int, 1=1rpm Int
345 SkipSpd 1 Hi 0rpm 43125 169/29 4C35 19509 Int, 1=1rpm Int
346 SkipSpd 2 Lo 0rpm 43126 169/30 4C36 19510 Int, 1=1rpm Int
347 SkipSpd 2 Hi 0rpm 43127 169/31 4C37 19511 Int, 1=1rpm Int
348 Jog Speed 50rpm 43128 169/32 4C38 19512 Int, 1=1rpm Int
349 Droop Speed 0% 43120 169/24 4C30 19504
Long,
1=0.01%
EInt
34A OverSpdTrip 110% 43129 169/33 4C39 19513 UInt, 1=1% UInt
350 Torques [350]
351 Max Torque 120% 43141 169/45 4C45 19525 Long, 1=1% EInt
352 IxR Comp Off 43142 169/46 4C46 19526 UInt UInt
353 IxR CompUsr 0% 43143 169/47 4C47 19527 Long, 1=0.1% EInt
354 Flux optim Off 43144 169/48 4C48 19528 UInt UInt
355 Max Power Off 43145 169/49 4C49 19529 Long, 1=1% EInt
360
Preset
References
[360]
361 Motor Pot Non volatile 43131 169/35 4C3B 19515 UInt UInt
362 Preset Ref 1 0 43132 169/36 4C3C 19516 Long, 1=0.001 EInt
363 Preset Ref 2 250 43133 169/37 4C3D 19517 Long, 1=0.001 EInt
364 Preset Ref 3 500 43134 169/38 4C3E 19518 Long, 1=0.001 EInt
365 Preset Ref 4 750 43135 169/39 4C3F 19519 Long, 1=0.001 EInt
366 Preset Ref 5 1000 43136 169/40 4C40 19520 Long, 1=0.001 EInt
367 Preset Ref 6 1250 43137 169/41 4C41 19521 Long, 1=0.001 EInt
368 Preset Ref 7 1500 43138 169/42 4C42 19522 Long, 1=0.001 EInt
369
Key Ref Mode MotPot 43139 169/43 4C43 19523 UInt UInt
370
PI Speed
Control [370]
371 Spd PI Auto Off 43151 169/55 4C4F 19535 UInt UInt
372 Spd P Gain 5 43152 169/56 4C50 19536 Long, 1=0.1 EInt
373 Spd I Time 0,14 s 43153 169/57 4C51 19537 Long, 1=0.01s EInt
380
PID Process
Control [380]
381 PID Control Off 43154 169/58 4C52 19538 UInt UInt
383 PID P Gain 1 43156 169/60 4C54 19540 Long, 1=0.1 EInt
384 PID I Time 1s 43157 169/61 4C55 19541 Long, 1=0.01s EInt
385 PID D Time 0s 43158 169/62 4C56 19542 Long, 1=0.01s EInt
386 PID<MinSpd Off 43371 170/20 4D2B 19755 Long, 1=0.01s EInt
387 PID Act Marg 0 43372 170/21 4D2C 19756 Long, 1=0.001 EInt
388 PID Stdy Tst Off 43373 170/22 4D2D 19757 Long, 1=0.01s EInt
389 PID Stdy Mar 0 43374 170/23 4D2E 19758 Long, 1=0.001 EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
