186 CG Drives & Automation 01-7492-01r1
Run Status [72D]
This menu indicates what is blocking the drive from starting
to run.
11.7.3 Stored values [730]
The shown values are the actual values built up over time. Values
are stored at power down and updated again at power up.
Run Time [731]
Displays the total time that the AC drive has been in the
Run Mode.
Reset Run Time [7311]
Reset the run time counter. The stored information will be
erased and a new registration period will start.
Mains time [732]
Displays the total time that the AC drive has been connected
to the mains supply. This timer cannot be reset.
Energy [733]
Displays the total energy consumption since the last energy
reset [7331] took place.
72D Run Status
Default: OK
OK 0
Nothing blocks the motor from
starting to run.
No Run cmd 1 Missing run command.
No Enable
cmd
2 Missing enable command.
Sleep 3 Blocked by sleep.
Pump
Blocked
4 Blocked by pump functionality.
Trip 5 Blocked by a trip.
STO 6 Blocked by STO.
Int Blocked 7
Blocked by internal condition (setup
problem e.g. failed ID-run not reset).
PEBBs nok 8
Blocked by PEBBs (all PEBBs not
ready).
DC-link nok 9
Blocked by DC-link (DC-voltage not
ready).
PPU load/
cpy
10 Blocked by PPU load or copy.
Opt search 11
Blocked by search for options (trying
to establish communication with
built-in option boards).
Opt blocked 12
Blocked by option software
(functionality in a non-standard
software is blocking run).
NOTE: The drive may be running even if blocked, e.g.
due to commissioning or stopping.
731 Run Time
Unit: hh:mm:ss (hours: minutes: seconds)
Range: 00: 00: 00–262143: 59: 59
7311 Reset RunTm
Default: No
No 0
Yes 1
NOTE: After reset the setting automatically reverts to
“No”.
732 Mains Time
Unit: hh:mm:ss (hours: minutes: seconds)
Range: 00: 00: 00–262143: 59: 59
733 Energy
Unit: Wh (shows Wh, kWh, MWh or GWh)
Range:
0.0–1GWh,
Counter will restart at 0 after 1GWh
