CG Drives & Automation 01-7492-01r1 Functional description 93
Supply Type [21C]
Set supply voltage type.
When changing to / from the “AFE Supply” selection, the
following parameters are set to following values:
11.2.2 Motor Data [220]
In this menu you enter the motor data to adapt the AC drive
to the connected motor. This is crucial for the control
accuracy as well as different read-outs and analogue output
signals.
Emotron VFX AC drive can control both Asynchronous
motors and Permanent magnet synchronous motor
(PMSM) select type of motor in menu [22I].
Motor M1 is selected as default and motor data entered will
be valid for motor M1. If you have more than one motor
you need to select the correct motor in menu [212] before
entering motor data.
Motor Voltage [221]
Set the nominal motor voltage.
21B Supply Volts
Default: Not defined
Not Defined 0
Inverter default value used. Only valid if
this parameter is never set.
220-240 VAC 1 Only valid for VFX48/52
380-415 VAC 3 Only valid for VFX48/52/69
440-480 VAC 4 Only valid for VFX48/52/69
500-525 VAC 5 Only valid for VFX52/69
550-600 VAC 6 Only valid for VFX69
660-690 VAC 7 Only valid for VFX69
21C Supply Type
Default: AC Supply
AC Supply 0 Normal AC supply
AFE Supply 1 DC supply voltage by AFE
DC Supply 2 DC supply voltage
AC/DC Suppl 3 AC/DC supply voltage
Menu to AFE from AFE
[523] DigIn 3 Sleep Off
[542] DigOut 3 Run Brake
[527] DigIn 7 Off Off
[561] VIO 1 Dest External Trip Off
[562] VIO 1 Source !D1 Off
[6151] CD 1 DigIn 7 Run
WARNING!
Do not work on a drive when a rotating
Permanent Magnet synchronous motor is
connected to it. A rotating PMSM motor
energizes the drive including its power
terminals.
NOTE 1: The parameters for motor data cannot be
changed during run mode.
NOTE 2: The default settings are for a standard 4-
pole motor according to the nominal power of the AC
drive.
NOTE 3: Parameter set cannot be changed during run
if the parameter set is set for different motors.
NOTE 4: Motor Data in the different sets M1 to M4
can be revert to default setting in menu “[243]
Default>Set”.
WARNING!
Enter the correct motor data to prevent
dangerous situations and assure correct
control.
221 Motor Volts
Default:
400 V for VFX48
500 V for VFX52
690 V forVFX 69
Range: 100-700 V
Resolution 1 V
NOTE: The Motor Volts value will always be stored as
a 3 digit value with a resolution of 1 V.
