CG Drives & Automation 01-7492-01r1 Functional description 87
11. Functional description
This chapter describes the menus and parameters in the
software. See chapter 10.2 Control panel with 4-line display
page 79 in chapter Operation for detailed information about
the Control panel.
Fig. 90 LCD display
11.1 Menus
Following chapters describes the menus and parameters in
the software. You will find a short description of each
function and information about default values, ranges, etc.
There are also tables containing communication
information. You will find the parameter number for all
available fieldbus options as well as the enumeration for the
data.
On our home page in the download area, you could find a
"Communication information" list and a list to note
“Parameter set” information.
11.1.1 Description of menu table
layout
Following two kinds of tables are used in this chapter.
1. Parameter cannot be changed during operation.
2. Parameter only for viewing.
3. Menu information as displayed on control panel.
For explanation of display text and symbols, see
chapter 10. Operation via the Control Panel page
79.
4. Factory setting of parameter (also showed on dis-
play).
5. Available settings for the menu, listed selections.
6. Communication integer value for the selection.
For use with communication bus interface (only if
selection type parameters).
7. Description of selection alternative, setting or range
(min - max value).
NOTE: Functions marked with the sign cannot be
changed during Run Mode.
332
Dec Time
Default:
222
Motor Freq
Default: 50 Hz
Range: 20.0 - 300.0 Hz
Resolution
