Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 181
Clock 1 Weekday [6815]
Weekdays when the clock function is active. Having entered
the editing mode, select or unselect the desired weekdays
with the cursor using the PREV and NEXT keys on the
control panel. Confirm by pressing ENTER. Exit the editing
mode and the activated weekdays will be viewed in the menu
display. The deactivated weekdays are replaced by a dash
mark “-” (e.g. “MTWTF - -”).
Example 1:
The output CLK1 shall be active Mondays to Fridays on
working hours, e.g. 08:00-17:00. This signal is used to start
e.g. a fan with virtual I/O.
Example 2:
The output CLK1 shall be active on weekends, all day.
Clock 2 [682]
Refer to the description for Clock 1 [681].
11.7 View Operation/Status
[700]
Menu with parameters for viewing all actual operational
data, such as speed, torque, power, etc.
11.7.1 Operation [710]
Process Value [711]
The process value is showing the process actual value,
depending on selection done in chapter, Process Source
[321].
Speed [712]
Displays the actual shaft speed.
Torque [713]
Displays the actual shaft torque.
Shaft power [714]
Displays the actual shaft power. Negative sign is used when
the shaft is generating mechanical power to the motor.
6815 Clk1Weekday
Default: MTWTFSS (all activated)
Range:
Monday, Tuesday, Wednesday, Thursday,
Friday, Saturday, Sunday.
NOTE: Please make sure that the correct time and
date settings are done for the real time clock, menu
group [930] “Clock”.
Menu Te xt Setting
6811
Clk1TimeOn 08:00
6812 Clk1TimeOff 17:00
6813 Clk1DateOn 2017-02-01 (date in the past)
6814
Clk1DateOff 2099-12-31 (Date in the future)
6815 Clk1Weekday MTWTF- -
561 VIO 1 Dest Run FWD
562
VIO 1 Source Clk1
Menu Te xt Setting
6811
Clk1TimeOn 0:00:00
6812 Clk1TimeOff 23:59:59
6813
Clk1DateOn 2017-02-01 (date in the past)
6814
Clk1DateOff 2099-12-31 (Date in the future)
6815 Clk1Weekday - - - - - SS
561
VIO 1 Dest Run FWD
562
VIO 1 Source Clk1
711 Process Val
Unit
Depends on selected Pocess source [321]
and Process Unit [322].
Resolution
Speed: 1 rpm, 4 digits
Other units: 3 digits
712 Speed
Unit: rpm
Resolution: 1 rpm, 4 digits
NOTE: If accessed via communication, the signal is
unreliable at speeds outside -32768 ... 32767.
713 Torque
Unit: %, Nm
Resolution: 1 %, 0.1 Nm
714 Shaft Power
Unit: W
Resolution: 1W
