Electrical Power [715]
Displays the actual electrical output power. Negative sign is
used when the motor is generating electrical power to the
drive unit.
Current [716]
Displays the actual output current.
Output Voltage [717]
Displays the actual output voltage.
Frequency [718]
Displays the actual output frequency.
DC Link Voltage [719]
Displays the actual DC link voltage.
IGBT Temperature [71A]
Displays the actual IGBT temperature, measured. The
signal is generated by a sensor in the IGBT module.
* The IGBT losses and temperature depend on the actual
operation condition, i.e. output current and voltage, DC-
voltage, switching frequency and cooling. At high
temperatures, the switching frequency is reduced down to
minimum 1.5 kHz to avoid trip due to over-temperature.
This feature provides for continuous and trouble free
operation of the drive even with high IGBT temperatures.
PT100_1_2_3 Temperature [71B]
Displays the actual PT100 temperature, for PT100 board 1.
PT100_4_5_6 Temperature [71C]
Displays the actual PT100 temperature, for PT100 board 2.
715 El Power
Unit: kW
Resolution: 1 W
716 Current
Unit: A
Resolution: 0.1 A
717 Output volt
Unit: V
Resolution: 0.1 V
718 Frequency
Unit: Hz
Resolution: 0.1 Hz
719 DC Voltage
Unit: V
Resolution: 0.1 V
71A IGBT Temp
Unit: °C
Resolution: 0.1°C
71B PT100 1,2,3
Unit: °C
Resolution: 1°C
71C PT100 4,5,6
Unit: °C
Resolution: 1°C
