Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Technical Data 207
14. Technical Data
14.1 Electrical specifications related to model
Emotron VFX 2.1 - IP20/21 version
* Available during limited time and as long as allowed by drive temperature.
Note: Use motor rated current for drive sizing.
Table 50 Typical motor power at mains voltage 230 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
Power
@230V
[kW]
Power
@230V
[HP]
Rated
current
[A]
Power
@230V
[kW]
Power
@230V
[HP]
Rated
current
[A]
48-025-20 38 5.5 7.5 25 4 5 20
C2
48-030-20 45 7.5 10 30 5.5 7.5 24
48-036-20 54 7.5 10 36 7.5 10 29
48-045-20 68 11 15 45 7.5 10 36
48-058-20 68 15 20 58 11 15 46
48-060-20 90 15 20 60 11 15 48
D2
48-072-20 108 18.5 25 72 15 20 58
48-088-20 132 22 30 88 18.5 25 70
48-105-20 132 30 40 105 22 30 84
48-142-20 170 37 50 142 30 40 114
E2
48-171-20 205 45 60 171 37 50 137
48-205-20 246 55 75 205 45 60 164
F248-244-20 293 75 100 244 55 75 195
48-293-20 352 90 125 293 75 100 235
48-365-20 438 110 150 365 90 125 292 FA2
Table 51 Typical motor power at mains voltage 400 and 460 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
Power
@400V
[kW]
Power
@460V
[hp]
Rated
current
[A]
Power
@400V
[kW]
Power
@460V
[hp]
Rated
current
[A]
48-025-20 38 11 15 25 7.5 10 20
C2
48-030-20 45 15 20 30 11 15 24
48-036-20 54 18.5 25 36 15 20 29
48-045-20 68 22 30 45 18.5 25 36
48-058-20 68 30 40 58 22 30 46
48-060-20 90 30 40 60 22 30 48
D2
48-072-20 108 37 50 72 30 40 58
48-088-20 132 45 60 88 37 50 70
48-105-20 132 55 75 105 45 60 84
