Emotron VFX 2.1 User Manual

208 Technical Data CG Drives & Automation 01-7492-01r1
* Available during limited time and as long as allowed by drive temperature.
* Available during limited time and as long as allowed by drive temperature.
48-142-20 170 75 100 142 55 75 114
E2
48-171-20 205 90 125 171 75 100 137
48-205-20 246 110 150 205 90 125 164
F2
48-244-20 293 132 200 244 110 150 195
48-293-20 352 160 250 293 132 200 235
48-365-20 438 200 300 365 160 250 292 FA2
Table 52 Typical motor power at mains voltage 575 and 690 V. AC drive main voltage range 500 - 690 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
Power
@575V
[hp]
Power
@690V
[kW]
Rated
current
[A]
Power
@575V
[hp]
Power
@690V
[kW]
Rated
current
[A]
69-002-20 3.2 1.5 1.5 2 1 0.75 1.6
C2(69)
69-003-20 4.8 2 2.2 3 1.5 1.5 2.4
69-004-20 6.4 3 3 4 2 2.2 3.2
69-006-20 9.6 4 4 6 3 3 4.8
69-008-20 12.8 5 5.5 8 4 4 6.4
69-010-20 16 7.5 7.5 10 5 5.5 8
69-013-20 20.8 10 11 13 7.5 7.5 10.4
69-018-20 29 15 15 18 10 11 14.4
69-021-20 34 20 18.5 21 15 15 16.8
69-025-20 40 25 22 25 20 18.5 20
69-033-20 53 30 30 33 25 22 26
D2(69)
69-042-20 67 40 37 42 30 30 34
69-050-20 80 50 45 50 40 37 40
69-058-20 93 60 55 58 40 45 46
Table 51 Typical motor power at mains voltage 400 and 460 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
Power
@400V
[kW]
Power
@460V
[hp]
Rated
current
[A]
Power
@400V
[kW]
Power
@460V
[hp]
Rated
current
[A]
