CG Drives & Automation 01-7492-01r1 Technical Data 209
Emotron VFX 2.1 - IP54 version (Model 48-430 and up also available as IP20)
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block (power module).
Table 53 Typical motor power at mains voltage 230 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame
size
(Number of
PEBB´s)**
IP
class
Power
@230V
[kW]
Power
@230V
[HP]
Rated
current
[A]
Power
@230V
[kW]
Power
@230V
[HP]
Rated
current
[A]
48-003-54 3.8 0.37 0.5 2.5 0.37 0.5 2.0
B
IP 54
wall
mounted
48-004-54 6.0 0.75 1 4.0 0.55 0.75 3.2
48-006-54 9.0 1.1 1.5 6.0 0.75 1 4.8
48-008-54 11.3 1.5 2 7.5 1.1 1.5 6.0
48-010-54 14.3 2.2 3 9.5 1.5 2 7.6
48-013-54 19.5 2.2 3 13.0 2.2 3 10.4
48-018-54 27.0 4 5 18.0 3 3 14.4
48-026-54 39 5.5 7.5 26 4 5 21
C
48-031-54 46 7.5 10 31 5.5 7.5 25
48-037-54 55 7.5 10 37 7.5 10 29.6
48-046-54 69 11 15 46 7.5 10 37
48-061-54 92 15 20 61 11 15 49
D
48-074-54 111 18.5 25 74 15 20 59
48-090-54 108 22 30 90 18.5 25 72
E
48-109-54 131 30 40 109 22 30 87
48-146-54 175 37 50 146 30 40 117
48-175-54 210 45 60 175 37 50 140
48-210-54 252 55 75 210 45 60 168
F48-250-54 300 75 100 250 55 75 200
48-295-54 354 90 125 295 75 100 236
48-365-54 438 110 150 365 90 125 292 FA
48-430-IP 516 110 150 430 110 125 344
H
IP 20
module
or IP54
cabinet
48-500-IP 600 160 200 500 110 150 400
48-590-IP 708 200 250 590 132 200 472 G2
48-660-IP 792 200 250 660 160 200 528
H2
48-730-IP 876 220 300 730 160 250 584
48-810-IP 972 250 350 810 200 250 648
G3
48-885-IP 1062 250 350 885 220 300 708
48-1010-IP 1212 315 400 1010 250 350 808
H3
48-1100-IP 1320 355 450 1100 250 350 880
48-1300-IP 1560 400 550 1300 315 450 1040
H4
48-1460-IP 1752 450 600 1460 355 500 1168
48-1710-IP 2052 560 750 1710 450 550 1368
H5
48-1820-IP 2184 600 800 1820 450 600 1456
48-2190-IP 2628 710 900 2190 560 750 1752 H6
48-2550-IP 3060 800 1100 2550 630 850 2040 H7
48-2920-IP 3504 900 1200 2920 750 1000 2336 H8
Larger sizes available on request
