210 Technical Data CG Drives & Automation 01-7492-01r1
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block (power module).
Table 54 Typical motor power at mains voltage 400 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
(Number of
PEBB´s)**
IP
class
Power
@400V
[kW]
Rated
current
[A]
Power
@400V
[kW]
Rated
current
[A]
48-003-54 3.8 0.75 2.5 0.55 2.0
B
IP 54
wall
mounted
48-004-54 6.0 1.5 4.0 1.1 3.2
48-006-54 9.0 2.2 6.0 1.5 4.8
48-008-54 11.3 3 7.5 2.2 6.0
48-010-54 14.3 4 9.5 3 7.6
48-013-54 19.5 5.5 13.0 4 10.4
48-018-54 27.0 7.5 18.0 5.5 14.4
48-026-54 39 11 26 7.5 21
C
48-031-54 46 15 31 11 25
48-037-54 55 18.5 37 15 29.6
48-046-54 69 22 46 18.5 37
48-061-54 92 30 61 22 49
D
48-074-54 111 37 74 30 59
48-090-54 108 45 90 37 72
E
48-109-54 131 55 109 45 87
48-146-54 175 75 146 55 117
48-175-54 210 90 175 75 140
48-210-54 252 110 210 90 168
F
48-250-54 300 132 250 110 200
48-295-54 354 160 295 132 236
48-365-54 438 200 365 160 292 FA
48-430-IP 516 220 430 200 344
H
IP 20
module
or IP54
cabinet
48-500-IP 600 250 500 220 400
48-590-IP 708 315 590 250 472 G2
48-660-IP 792 355 660 250 528
H2
48-730-IP 876 400 730 315 584
48-810-IP 972 450 810 355 648
G3
48-885-IP 1062 500 885 400 708
48-1010-IP 1212 560 1010 450 808
H3
48-1100-IP 1320 630 1100 500 880
48-1300-IP 1560 710 1300 560 1040
H4
48-1460-IP 1752 800 1460 630 1168
48-1710-IP 2052 900 1710 750 1368
H5
48-1820-IP 2184 1000 1820 800 1456
48-2190-IP 2628 1200 2190 1000 1752 H6
48-2550-IP 3060 1400 2550 1120 2040 H7
48-2920-IP 3504 1600 2920 1300 2336 H8
Larger sizes available on request
