Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Technical Data 211
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block (power module).
Table 55 Typical motor power at mains voltage 460 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame
size
(Number of
PEBB´s)**
IP
class
Power
@460V
[HP]
Rated
current
[A]
Power
@460V
[HP]
Rated
current
[A]
48-003-54 3.8 1 2.5 1 2.0
B
IP 54
wall
mounted
48-004-54 6.0 2 4.0 1.5 3.2
48-006-54 9.0 3 6.0 2 4.8
48-008-54 11.3 3 7.5 3 6.0
48-010-54 14.3 5 9.5 3 7.6
48-013-54 19.5 7.5 13.0 5 10.4
48-018-54 27.0 10 18.0 7.5 14.4
48-026-54 39 15 26 10 21
C
48-031-54 46 20 31 15 25
48-037-54 55 25 37 20 29.6
48-046-54 69 30 46 25 37
48-061-54 92 40 61 30 49
D
48-074-54 111 50 74 40 59
48-090-54 108 60 90 50 72
E
48-109-54 131 75 109 60 87
48-146-54 175 100 146 75 117
48-175-54 210 125 175 100 140
48-210-54 252 150 210 125 168
F
48-250-54 300 200 250 150 200
48-295-54 354 250 295 200 236
48-365-54 438 300 365 250 292 FA
48-430-IP 516 350 430 250 344
H
IP 20
module
or IP54
cabinet
48-500-IP 600 400 500 350 400
48-590-IP 708 500 590 400 472 G2
48-660-IP 792 550 660 450 528
H2
48-730-IP 876 600 730 500 584
48-810-IP 972 700 810 550 648
G3
48-885-IP 1062 750 885 600 708
48-1010-IP 1212 800 1010 700 808
H3
48-1100-IP 1320 900 1100 750 880
48-1300-IP 1560 1100 1300 800 1040
H4
48-1460-IP 1752 1250 1460 1000 1168
48-1710-IP 2052 1500 1710 1200 1368
H5
48-1820-IP 2184 1600 1820 1250 1456
48-2190-IP 2628 1900 2190 1500 1752 H6
48-2550-IP 3060 2100 2550 1700 2040 H7
48-2920-IP 3504 2500 2920 2000 2336 H8
Larger sizes available on request
