212 Technical Data CG Drives & Automation 01-7492-01r1
Emotron VFX 2.1 - IP54 version (Model 69-250 and up also available as IP20)
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block (power module).
Table 56 Typical motor power at mains voltage 525 V.
AC drive main voltage range, for VFX52: 440 - 525 V and for VFX69: 500 - 690 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
(Number of
PEBB´s)**
IP
class
Power
@525V
[kW]
Rated
current
[A]
Power
@525V
[kW]
Rated
current [A]
52-003-54 3.8 1.1 2.5 1.1 2.0
B
IP 54
wall
mounted
52-004-54 6.0 2.2 4.0 1.5 3.2
52-006-54 9.0 3 6.0 2.2 4.8
52-008-54 11.3 4 7.5 3 6.0
52-010-54 14.3 5.5 9.5 4 7.6
52-013-54 19.5 7.5 13.0 5.5 10.4
52-018-54 27.0 11 18.0 7.5 14.4
52-026-54 39 15 26 11 21
C
52-031-54 46 18.5 31 15 25
52-037-54 55 22 37 18.5 29.6
52-046-54 69 30 46 22 37
52-061-54 92 37 61 30 49
D
52-074-54 111 45 74 37 59
69-082-54 98 55 82 45 66
F69
69-090-54 108 55 90 45 72
69-109-54 131 75 109 55 87
69-146-54 175 90 146 75 117
69-175-54 210 110 175 90 140
69-200-54 240 132 200 110 160
69-250-IP 300 160 250 132 200
H69 (2)
IP 20
module
or IP54
cabinet
69-300-IP 360 200 300 160 240
69-375-IP 450 250 375 200 300
69-400-IP 480 250 400 220 320
69-430-IP 516 300 430 250 344
I69 (3)
69-500-IP 600 315 500 300 400
69-595-IP 720 400 600 315 480
69-650-IP 780 450 650 355 520
J69 (4)69-720-IP 864 500 720 400 576
69-800-IP 960 560 800 450 640
69-995-IP 1200 630 1000 500 800 KA69 (5)
69-1K2-IP 1440 800 1200 630 960 K69 (6)
69-1K4-IP 1680 1000 1400 800 1120
L69 (7)
69-1K6-IP 1920 1100 1600 900 1280 M69 (8)
69-1K8-IP 2160 1300 1800 1000 1440
N69 (9)
69-2K0-IP 2400 1400 2000 1100 1600 O69 (10)
69-2K2-IP 2640 1600 2200 1200 1760 P69 (11)
69-2K4-IP 2880 1700 2400 1400 1920 Q69 (12)
69-2K6-IP 3120 1900 2600 1500 2080
R69 (13)
69-2K8-IP 3360 2000 2800 1600 2240 S69 (14)
69-3K0-IP 3600 2200 3000 1700 2400
T69 (15)
