228 Menu List CG Drives & Automation 01-7492-01r1
229 Motor ID-Run Off 43049 168/208 4BE9 19433 UInt UInt
22A Motor Sound F 43050 168/209 4BEA 19434 UInt UInt
22B Encoder Off 43051 168/210 4BEB 19435 UInt UInt
22C Enc Pulses 1024 43052 168/211 4BEC 19436 Long, 1=1 EInt
22D Enc Speed 0rpm 42911 168/70 4B5F 19295 Int, 1=1rpm Int
22E
Motor PWM
[22E]
22E1 PWM Fswitch 3000Hz 43053 168/212 4BED 19437 UInt, 1=1Hz UInt
22E2 PWM Mode Standard 43054 168/213 4BEE 19438 UInt UInt
22E3 PWM Random Off 43055 168/214 4BEF 19439 UInt UInt
22E4 Udc filter Off 43040 168/199 4BE0 19424 UInt UInt
22F Enc Puls Ctr 0 42912 168/71 4B60 19296 Long, 1=1 Int
22G
Encoder fault
and speed
monitoring
[22G]
22G1 Enc F Delay Off 43056 168/215 4BF0 19440 Long, 1=0.01s EInt
22G2 Enc F Band 10% 43057 168/216 4BF1 19441 Long, 1=1% EInt
22G3 Max EncFCtr 0.000s 42913 168/72 4B61 19297
Long,
1=0.001s
EInt
22H Phase order Normal 43058 168/217 4BF2 19442 UInt UInt
22I Motor Type Async 43059 168/218 4BF3 19443 UInt UInt
22J
Extend data
[22J]
22J1 BEMF [Motor] V 43391 170/40 4D3F 19775 Long, 1=0.1V EInt
22J2 Rs (mΩ/ph) [Motor] 43392 170/41 4D40 19776
Long,
1=0.000001
EInt
22J3 Lsd (mH/ph) [Motor] 43393 170/42 4D41 19777 Long, 1=0.001 EInt
22J4 Lsq (mH/ph) [Motor] 43394 170/43 4D42 19778 Long, 1=0.001 EInt
230 Mot Protect
231 Mot I2t Type Trip 43061 168/220 4BF5 19445 UInt UInt
232 Mot I2t Curr 100% 43062 168/221 4BF6 19446 Long, 1=1% EInt
233 Mot I2t Time 60s 43063 168/222 4BF7 19447 Long, 1=1s EInt
234 Thermal Prot Off 43064 168/223 4BF8 19448 UInt UInt
235 Motor Class F 140°C 43065 168/224 4BF9 19449 UInt UInt
236 PT100 Inputs PT100 1+2+3 43066 168/225 4BFA 19450 UInt UInt
237 Motor PTC Off 43067 168/226 4BFB 19451 UInt UInt
238 I²t Min Spd 0rpm 43386 170/35 4D3A 19770 Int, 1=1rpm Int
240
Parameter
Set Handling
[240]
241 Select Set A 43022 168/181 4BCE 19406 UInt UInt
242 Copy Set A>B 43021 168/180 4BCD 19405 UInt UInt
243 Default>Set A 43023 168/182 4BCF 19407 UInt UInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
