Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Menu List 229
244 Copy to CP No Copy 43024 168/183 4BD0 19408 UInt UInt
245 Load from CP No Copy 43025 168/184 4BD1 19409 UInt UInt
246 ComFlt Set Keep last 42653 167/67 4A5D 19037 UInt UInt
250
Trip
Autoreset/Trip
Conditions
[250]
251 No of Trips 0 43071 168/230 4BFF 19455 UInt, 1=1 UInt
252 DriveProtect
2521 Over temp Off 43072 168/231 4C00 19456 Long, 1=1s EInt
2522 Over volt D Off 43075 168/234 4C03 19459 Long, 1=1s EInt
2523 Over volt G Off 43076 168/235 4C04 19460 Long, 1=1s EInt
2524 Over volt Off 43077 168/236 4C05 19461 Long, 1=1s EInt
2525 Undervoltage Off 43088 168/247 4C10 19472 Long, 1=1s EInt
2526 Over curr F Off 43082 168/241 4C0A 19466 Long, 1=1s EInt
2527 Power Fault Off 43087 168/246 4C0F 19471 Long, 1=1s EInt
2528 LC Level Off 43099 169/3 4C1B 19483 Long, 1=1s EInt
2529 LC Level TT Trip 43100 169/4 4C1C 19484 UInt UInt
253 MotorProtect
2531 Motor Lost Off 43083 168/242 4C0B 19467 Long, 1=1s EInt
2532 Locked Rotor Off 43086 168/245 4C0E 19470 Long, 1=1s EInt
2533 Motor I2t Off 43073 168/232 4C01 19457 Long, 1=1s EInt
2534 Motor I2t TT Trip 43074 168/233 4C02 19458 UInt UInt
2535 PT100 Off 43078 168/237 4C06 19462 Long, 1=1s EInt
2536 PT100 TT Trip 43079 168/238 4C07 19463 UInt UInt
2537 PTC Off 43084 168/243 4C0C 19468 Long, 1=1s EInt
2538 PTC TT Trip 43085 168/244 4C0D 19469 UInt UInt
2539 Over speed Off 43096 169/0 4C18 19480 Long, 1=1s EInt
253A Ext Mot Temp Off 43097 169/1 4C19 19481 Long, 1=1s EInt
253B Ext Mot TT Trip 43098 169/2 4C1A 19482 UInt UInt
253C Brk Fault Off 43070 168/229 4BFE 19454 Long, 1=1s EInt
253D Encoder Off 43561 170/210 4DE9 19945 Long, 1=1s EInt
254 Comm & I/O
2541 Com Error Off 43089 168/248 4C11 19473 Long, 1=1s EInt
2542 Com Error TT Trip 43090 168/249 4C12 19474 UInt UInt
2543 AnIn<Offset Off 43566 170/215 4DEE 19950 Long, 1=1s EInt
2544 AnIn TT Trip 43567 170/216 4DEF 19951 UInt UInt
255 Load monitor
2551 Min Alarm Off 43091 168/250 4C13 19475 Long, 1=1s EInt
2552 Min Alarm TT Trip 43092 168/251 4C14 19476 UInt UInt
2553 Max Alarm Off 43093 168/252 4C15 19477 Long, 1=1s EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
