230 Menu List CG Drives & Automation 01-7492-01r1
2554 Max Alarm TT Trip 43094 168/253 4C16 19478 UInt UInt
256 Pump
2561 Pump Off 43095 168/254 4C17 19479 Long, 1=1s EInt
257 Crane
2571 Crane Deviat Off 43562 170/211 4DEA 19946 Long, 1=1s EInt
2572 Crane Comm Off 43563 170/212 4DEB 19947 Long, 1=1s EInt
258 External
2581 Ext Trip 1 Off 43080 168/239 4C08 19464 Long, 1=1s EInt
2582 Ext Trip1 TT Trip 43081 168/240 4C09 19465 UInt UInt
2583 Ext Trip 2 Off 43564 170/213 4DEC 19948 Long, 1=1s EInt
2584 Ext Trip2 TT Trip 43565 170/214 4DED 19949 UInt UInt
2585 Ext Trip 3 Off 43568 170/217 4DF0 19952 Long, 1=1s EInt
2586 Ext Trip3 TT Trip 43569 170/218 4DF1 19953 UInt UInt
2587 Ext Trip 4 Off 43570 170/219 4DF2 19954 Long, 1=1s EInt
2588 Ext Trip4 TT Trip 43571 170/220 4DF3 19955 UInt UInt
260
Serial
Communication
[260]
261 Com Type RS232/485 43031 168/190 4BD7 19415 UInt UInt
262 RS232/485
2621 Baudrate 9600 43032 168/191 4BD8 19416 UInt UInt
2622 Address 1 43033 168/192 4BD9 19417 UInt, 1=1 UInt
263 Fieldbus
2631 Address 62 43034 168/193 4BDA 19418 UInt, 1=1 UInt
2632 PrData Mode Basic 43035 168/194 4BDB 19419 UInt UInt
2633 Read/Write RW 43036 168/195 4BDC 19420 UInt UInt
2634 AddPrValues 0 43039 168/198 4BDF 19423 UInt, 1=1 UInt
2635 CANBaudrate 8 43030 168/189 4BD6 19414 UInt, 1=1 UInt
264
Communication
Fault [264]
2641 ComFlt Mode Off 43037 168/196 4BDD 19421 UInt UInt
2642 ComFlt Time 0,5s 43038 168/197 4BDE 19422 Long, 1=0.1s EInt
2643 485Flt Mode Off 42979 168/138 4BA3 19363 UInt UInt
2644 485Flt Time 0,5s 42980 168/139 4BA4 19364 Long, 1=0.1s EInt
2645
KbdComFMode
Trip 42981 168/140 4BA5 19365 UInt UInt
2646
KbdComFTime
2s 42982 168/141 4BA6 19366 UInt, 1=0.1s UInt
2647
CPportFMode
Trip 42983 168/142 4BA7 19367 UInt UInt
2648
CPportFTime
10.0s 42984 168/143 4BA8 19368 UInt, 1=0.1s UInt
265
Ethernet
[265]
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
