Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Menu List 231
2651 IP Address 0.0.0.0
42701 167/115 4A8D 19085 UInt, 1=1 UInt
42702 167/116 4A8E 19086 UInt, 1=1 UInt
42703 167/117 4A8F 19087 UInt, 1=1 UInt
42704 167/118 4A90 19088 UInt, 1=1 UInt
2652 MAC Address 000000000000
42705 167/119 4A91 19089 UInt, 1=1 UInt
42706 167/120 4A92 19090 UInt, 1=1 UInt
42707 167/121 4A93 19091 UInt, 1=1 UInt
42708 167/122 4A94 19092 UInt, 1=1 UInt
42709 167/123 4A95 19093 UInt, 1=1 UInt
42710 167/124 4A96 19094 UInt, 1=1 UInt
2653 Subnet Mask 0.0.0.0
42711 167/125 4A97 19095 UInt, 1=1 UInt
42712 167/126 4A98 19096 UInt, 1=1 UInt
42713 167/127 4A99 19097 UInt, 1=1 UInt
42714 167/128 4A9A 19098 UInt, 1=1 UInt
2654 Gateway 0.0.0.0
42715 167/129 4A9B 19099 UInt, 1=1 UInt
42716 167/130 4A9C 19100 UInt, 1=1 UInt
42717 167/131 4A9D 19101 UInt, 1=1 UInt
42718 167/132 4A9E 19102 UInt, 1=1 UInt
2655 DHCP Off 42719 167/133 4A9F 19103 UInt UInt
266
Fieldbus
Signals [266]
0
2661 FB S1/Wr1 0 42801 167/215 4AF1 19185 UInt, 1=1 UInt
2662 FB S2/Wr2 0 42802 167/216 4AF2 19186 UInt, 1=1 UInt
2663 FB S3/Wr3 0 42803 167/217 4AF3 19187 UInt, 1=1 UInt
2664 FB S4/Wr4 0 42804 167/218 4AF4 19188 UInt, 1=1 UInt
2665 FB S5/Wr5 0 42805 167/219 4AF5 19189 UInt, 1=1 UInt
2666 FB S6/Wr6 0 42806 167/220 4AF6 19190 UInt, 1=1 UInt
2667 FB S7/Wr7 0 42807 167/221 4AF7 19191 UInt, 1=1 UInt
2668 FB S8/Wr8 0 42808 167/222 4AF8 19192 UInt, 1=1 UInt
2669 FB S9/Rd1 0 42809 167/223 4AF9 19193 UInt, 1=1 UInt
266A FB S10/Rd2 0 42810 167/224 4AFA 19194 UInt, 1=1 UInt
266B FB S11/Rd3 0 42811 167/225 4AFB 19195 UInt, 1=1 UInt
266C FB S12/Rd4 0 42812 167/226 4AFC 19196 UInt, 1=1 UInt
266D FB S13/Rd5 0 42813 167/227 4AFD 19197 UInt, 1=1 UInt
266E FB S14/Rd6 0 42814 167/228 4AFE 19198 UInt, 1=1 UInt
266F FB S15/Rd7 0 42815 167/229 4AFF 19199 UInt, 1=1 UInt
266G FB S16/Rd8 0 42816 167/230 4B00 19200 UInt, 1=1 UInt
269 FB Status
270
Wireless
[270]
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
