Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 161
Max Alarm 20
The max alarm level has been
reached.
Max PreAlarm 21
The max pre alarm level has been
reached.
Min Alarm 22
The min alarm level has been
reached.
Min PreAlarm 23
The min pre alarm Level has been
reached.
CA1 24 Analogue comparator 1 output.
CA2 25 Analogue comparator 2 output.
CA3 26 Analogue comparator 3 output.
CA4 27 Analogue comparator 4 output.
L1 28 Logic 1 expression output
L2 29 Logic 2 expression output
L3 30 Logic 3 expression output
L4 31 Logic 4 expression output
F1 32 Flip flop 1 output
F2 33 Flip flop 2 output
F3 34 Flip flop 3 output
F4 35 Flip flop 4 output
Operation 36
Run command is active or AC drive
running. The signal can be used to
control the mains contactor if the AC
drive is equipped with Standby
supply option.
T1Q 37 Timer 1 output
T2Q 38 Timer 2 output.
T3Q 39 Timer 3 output
T4Q 40 Timer 4 output
Sleeping 41 Sleeping function activated
Crane Deviat 42 Tripped on deviation
PumpSlave1 43 Activate pump slave 1
PumpSlave2 44 Activate pump slave 2
PumpSlave3 45 Activate pump slave 3
PumpSlave4 46 Activate pump slave 4
PumpSlave5 47 Activate pump slave 5
PumpSlave6 48 Activate pump slave 6
PumpMaster1 49 Activate pump master 1
PumpMaster2 50 Activate pump master 2
PumpMaster3 51 Activate pump master 3
PumpMaster4 52 Activate pump master 4
PumpMaster5 53 Activate pump master 5
PumpMaster6 54 Activate pump master 6
All Pumps 55 All pumps are running
Only Master 56 Only the master is running
Loc/Rem 57
Local/Rem mode indication
Local = 1, Remote = 0
Standby 58 Standby supply option is active
PTC Trip 59 Trip when function is active
PT100 Trip 60 Trip when function is active
Overvolt 61 Overvoltage due to high main voltage
Overvolt G 62 Overvoltage due to generation mode
Overvolt D 63 Overvoltage due to deceleration
Acc 64 Acceleration along the acc. ramp
Dec 65 Deceleration along the dec. ramp
I
2
t66I
2
t limit protection active
V-Limit 67 Overvoltage limit function active
C-Limit 68 Overcurrent limit function active
Overtemp 69 Over temperature warning
Low voltage 70 Low voltage warning
DigIn 1 71 Digital input 1
DigIn 2 72 Digital input 2
DigIn 3 73 Digital input 3
DigIn 4 74 Digital input 4
DigIn 5 75 Digital input 5
DigIn 6 76 Digital input 6
DigIn 7 77 Digital input 7
DigIn 8 78 Digital input 8
ManRst Trip 79
Active trip that needs to be manually
reset
Com Error 80 Serial communication lost
External Fan 81
The AC drive requires external
cooling. Internal fans are active.
LC Pump 82 Activate liquid cooling pump
LC HE Fan 83
Activate liquid cooling heat
exchanger fan
LC Level 84 Liquid cooling low level signal active
RunR 85
Positive speed (>0.5%), i.e. forward/
clockwise direction.
RunL 86
Negative speed (<0.5%), i.e. reverse
counter clockwise direction.
Com Active 87 Fieldbus communication active.
Brk Fault 88 Tripped on brake fault (not released)
BrkNotEngage 89
Warning and continued operation
(keep torque) due to Brake not
engaged during stop.
Option 90
Failure occurred in built-in option
board.
NOT1 91 NOT gate 1 output
NOT2 92 NOT gate 2 output
NOT3 93 NOT gate 3 output
NOT4 94 NOT gate 4 output
NOT5 95 NOT gate 5 output
