CG Drives & Automation 01-7492-01r1 179
Counter 1 Reset [6712]
Selection of the digital signal used as reset signal for counter
1. Counter 1 is cleared to 0 and held to 0 as long as reset
input is active (high).
Counter 1 High value [6713]
Sets counter 1 high limit value. Counter 1 value is clamped
to selected high limit value and the counter 1 output
(CTR1) is active (high) when the counter value equals the
high value.
Counter 1 Low value [6714]
Sets counter 1 low limit value. Counter 1 output (CTR1) is
de-activated (low) when the counter value is equal or smaller
than the low value.
Counter 1 Decrement timer [6715]
Sets counter 1 automatic decrement timer value. The
counter 1 is decremented by 1 after elapsed decrement time
and if no new trigger has happened within the decrement
time. The decrement timer is reset to 0 at every counter
1 trig pulse.
Counter 1 Value [6719]
Parameter shows the actual value of counter 1.
Counter2 [672]
Refer to description for Counter 1 [671].
Counter 2 Trigger [6721]
Function is identical to Counter 1 Trigger [6711].
Counter 2 Reset [6722]
Function is identical to Counter 1 Reset [6712].
Counter 2 High value [6723]
Function is identical to Counter 1 High value [6713].
Counter 2 Low value [6724]
Function is identical to Counter 1 Low value [6714].
NOTE: Reset input has top priority.
6712 C1 Reset
Default: Off
Selection: Same as in menu DigOut 1
[541].
NOTE: Value 0 means that counter output is always
true (high).
6713 C1 High Val
Default: 0
Range: 0 - 10000
NOTE: Counter high value has priority so if high and
low values are equal then the counter output is de-
activated when the value is smaller than the low
value.
6714 C1 Low Val
Default: 0
Range: 0 - 10000
6715 C1 DecTimer
Default: Off
Range: Off, 1–3600 s (Off=0)
NOTE: Counter 1 value is common for all parameter
sets.
NOTE: The value is volatile and lost at power down.
6719 C1 Value
Default: 0
Range: 0 - 10000
6721 C2 Trig
Default: Off
Selection: Same as in menu DigOut 1
[541].
6722 C2 Reset
Default: Off
Selection: Same as in menu DigOut 1
[541].
6723 C2 High Val
Default: 0
Range: 0 - 10000
6724 C2 Low Val
Default: 0
Range: 0 - 10000
