Emotron VFX 2.1 User Manual

218 Technical Data CG Drives & Automation 01-7492-01r1
Dimensions and weights for models Emotron VFX48 - IP20/21 version
The table below gives an overview of the dimensions and
weights of the Emotron VFX IP20/21 version.
These AC drives are available as wall mounted modules;
The IP20 version is optimised for cabinet mounting.
With the optional top cover, protection class is in
compliance with IP21, making it suitable for mounting
directly on the electrical room wall.
The protection classes IP20 and IP21 are defined according
to the EN 60529 standard.
H1 = Enclosure height.
H2 = Total height including cable interface.
* with optional top cover
H1 = Enclosure height.
H2 = Total height including cable interface.
* with optional top cover
Table 61 Mechanical specifications, VFX48 - IP20 and IP21 version
Models VFX48
Frame
size
IP20
Dim. H1/H2 x W x D
mm (in)
IP21*
Dim. H1/H2 x W x D
mm (in)
IP20/21
Weight
kg (lb)
025 to 058 C2
438 / 536 x 176 x 267
(17.2 / 21.1 x 6.9 x 10.5)
438 / 559 x 196 x 282
(17.2 / 22 x 7.7 x 11.1)
17 (37.5)
060 to 105 D2
545 / 658 x 220 x 291
(21.5 / 25.9 x 8.7 x 11.5)
545 / 670 x 240 x 307
(21.5 / 26.4 x 9.5 x 12.1)
30 (66)
142 to 171 E2
956 / 956 x 275 x 294
(37.6 / 37.6 x 10.8 x 11.6)
956 / 956 x 275 x 323
(37.6 / 37.6 x 10.8 x 12.7)
53 (117)
205 to 293 F2
956 / 956 x 335 x 294
(37.6 / 37.6 x 13.2 x 11.6)
956 / 956 x 335 x 323
(37.6 / 37.6 x 13.2 x 12.7)
69 (152)
365 FA2
1090 / 1250 x 335 x 306
(42.9 / 49.5 x 13.2 x 12.1)
- 84 (185)
Table 62 Mechanical specifications, VFX69 - IP20 and IP21 version
Models VFX69
Frame
size
IP20
Dim. H1/H2 x W x D
mm (in)
IP20
Weight
kg (lb)
002 to 025 C2(69)
438 / 536 x 176 x 267
(17.2 / 21.1 x 6.9 x 10.5)
17 (37.5)
033 to 058 D2(69)
545 / 658 x 220 x 291
(21.5 / 25.9 x 8.7 x 11.5)
30 (66)
