Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Menu List 241
527 DigIn 7 Off 43247 169/151 4CAF 19631 UInt UInt
528 DigIn 8 Reset 43248 169/152 4CB0 19632 UInt UInt
529 B1 DigIn 1 Off 43501 170/150 4DAD 19885 UInt UInt
52A B1 DigIn 2 Off 43502 170/151 4DAE 19886 UInt UInt
52B B1 DigIn 3 Off 43503 170/152 4DAF 19887 UInt UInt
52C B2 DigIn 1 Off 43504 170/153 4DB0 19888 UInt UInt
52D B2 DigIn 2 Off 43505 170/154 4DB1 19889 UInt UInt
52E B2 DigIn 3 Off 43506 170/155 4DB2 19890 UInt UInt
52F B3 DigIn 1 Off 43507 170/156 4DB3 19891 UInt UInt
52G B3 DigIn 2 Off 43508 170/157 4DB4 19892 UInt UInt
52H B3 DigIn 3 Off 43509 170/158 4DB5 19893 UInt UInt
530
Analogue
Outputs [530]
531 AnOut1 Fc Speed 43251 169/155 4CB3 19635 UInt UInt
532 AnOut1 Setup 4-20mA 43252 169/156 4CB4 19636 UInt UInt
533
AnOut 1 Advan
5331 AnOut 1 Min 4mA 43253 169/157 4CB5 19637 Long, 1=0.01 EInt
5332 AnOut 1 Max 20mA 43254 169/158 4CB6 19638 Long, 1=0.01 EInt
5333 AnOut1Bipol 20mA 43255 169/159 4CB7 19639 Long, 1=0.01 EInt
5334 AnOut1FCMin Min 43256 169/160 4CB8 19640 UInt UInt
5335 AnOut1VaMin 0 43545 170/194 4DD9 19929 Long, 1=0.001 EInt
5336
AnOut1FCMax Max 43257 169/161 4CB9 19641 UInt UInt
5337
AnOut1VaMax 0 43555 170/204 4DE3 19939 Long, 1=0.001 EInt
534
AnOut2 Fc Torque 43261 169/165 4CBD 19645 UInt UInt
535
AnOut2 Setup 4-20mA 43262 169/166 4CBE 19646 UInt UInt
536
AnOut2 Advan
5361 AnOut2 Min 4mA 43263 169/167 4CBF 19647 Long, 1=0.01 EInt
5362 AnOut2 Max 20mA 43264 169/168 4CC0 19648 Long, 1=0.01 EInt
5363 AnOut2Bipol 20mA 43265 169/169 4CC1 19649 Long, 1=0.01 EInt
5364 AnOut2FcMin Min 43266 169/170 4CC2 19650 UInt UInt
5365
AnOut2VaMin 0 43546 170/195 4DDA 19930 Long, 1=0.001 EInt
5366
AnOut2FcMax Max 43267 169/171 4CC3 19651 UInt UInt
5367
AnOut2VaMax 0 43556 170/205 4DE4 19940 Long, 1=0.001 EInt
540
Digital
Outputs [540]
541 DigOut 1 Ready 43271 169/175 4CC7 19655 UInt UInt
542 DigOut2 Brake 43272 169/176 4CC8 19656 UInt UInt
550 Relays [550]
551 Relay 1 Trip 43273 169/177 4CC9 19657 UInt UInt
552 Relay 2 Run 43274 169/178 4CCA 19658 UInt UInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
