CG Drives & Automation 01-7492-01r1 Menu List 243
56F VIO 8 Dest Off 43295 169/199 4CDF 19679 UInt UInt
56G VIO 8 Source STO Active 43296 169/200 4CE0 19680 UInt UInt
600
Logical
Functions and
Timers [600]
610
Comparators
[610]
611
Setup
Analogue
Comparator 1
[611]
6111 CA1 Value Speed 43400 170/49 4D48 19784 UInt UInt
6112 CA1 LevelHI 300rpm 43401 170/50 4D49 19785 Long, 1=0.001 EInt
6113 CA1 LevelLO 200rpm 43402 170/51 4D4A 19786 Long, 1=0.001 EInt
6114 CA1 Type Hysteresis 43403 170/52 4D4B 19787 UInt UInt
6115 CA1 Polar Unipolar 43404 170/53 4D4C 19788 UInt UInt
6116 CA1 Set Dly 0s 43405 170/54 4D4D 19789 Long, 1=1s EInt
6117 CA1 Res Dly 0s 43406 170/55 4D4E 19790 Long, 1=1s EInt
6118 CA1 Tmr Val 0s 43407 170/56 4D4F 19791 Long, 1=1s EInt
612
CA2 Setup
[612]
6121 CA2 Value Torque 43408 170/57 4D50 19792 UInt UInt
6122 CA2 LevelHI 20 43409 170/58 4D51 19793 Long, 1=0.001 EInt
6123 CA2 LevelLO 10 43410 170/59 4D52 19794 Long, 1=0.001 EInt
6124 CA2 Type Hysteresis 43411 170/60 4D53 19795 UInt UInt
6125 CA2 Polar Unipolar 43412 170/61 4D54 19796 UInt UInt
6126 CA2 Set Dly 0s 43413 170/62 4D55 19797 Long, 1=1s EInt
6127 CA2 Res Dly 0s 43414 170/63 4D56 19798 Long, 1=1s EInt
6128 CA2 Tmr Val 0s 43415 170/64 4D57 19799 Long, 1=1s EInt
613
CA3 Setup
[613]
6131 CA3 Value Process Val 43416 170/65 4D58 19800 UInt UInt
6132 CA3 LevelHI 300 43417 170/66 4D59 19801 Long, 1=0.001 EInt
6133 CA3 LevelLO 200 43418 170/67 4D5A 19802 Long, 1=0.001 EInt
6134 CA3 Type Hysteresis 43419 170/68 4D5B 19803 UInt UInt
6135 CA3 Polar Unipolar 43420 170/69 4D5C 19804 UInt UInt
6136 CA3 Set Dly 0s 43421 170/70 4D5D 19805 Long, 1=1s EInt
6137 CA3 Res Dly 0s 43422 170/71 4D5E 19806 Long, 1=1s EInt
6138 CA3 Tmr Val 0s 43423 170/72 4D5F 19807 Long, 1=1s EInt
614
CA4 Setup
[614]
6141 CA4 Value Process Err 43424 170/73 4D60 19808 UInt UInt
6142 CA4 LevelHI 100 43425 170/74 4D61 19809 Long, 1=0.001 EInt
6143 CA4 LevelLO -100 43426 170/75 4D62 19810 Long, 1=0.001 EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
To Next Page
