Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Menu List 245
6421 L2 Expr ((1.2).3).4 43461 170/110 4D85 19845 UInt UInt
6422 L2 Input 1 CA1 43462 170/111 4D86 19846 UInt UInt
6423 L2 Op 1 & 43463 170/112 4D87 19847 UInt UInt
6424 L2 Input 2 NOT1 43464 170/113 4D88 19848 UInt UInt
6425 L2 Op 2 & 43465 170/114 4D89 19849 UInt UInt
6426 L2 Input 3 Run 43466 170/115 4D8A 19850 UInt UInt
6427 L2 Op 3 . 43467 170/116 4D8B 19851 UInt UInt
6428 L2 Input 4 Off 43468 170/117 4D8C 19852 UInt UInt
6429 L2 Set Dly 0s 43469 170/118 4D8D 19853 Long, 1=1s EInt
642A L2 Res Dly 0s 43470 170/119 4D8E 19854 Long, 1=1s EInt
642B L2 Tmr Val 0s 43471 170/120 4D8F 19855 Long, 1=1s EInt
643 Logic 3 31095 121/239 2447 1095 UInt, 1=1 UInt
6431 L3 Expr ((1.2).3).4 43472 170/121 4D90 19856 UInt UInt
6432 L3 Input 1 CA1 43473 170/122 4D91 19857 UInt UInt
6433 L3 Op 1 & 43474 170/123 4D92 19858 UInt UInt
6434 L3 Input 2 NOT1 43475 170/124 4D93 19859 UInt UInt
6435 L3 Op 2 & 43476 170/125 4D94 19860 UInt UInt
6436 L3 Input 3 Run 43477 170/126 4D95 19861 UInt UInt
6437 L3 Op 3 . 43478 170/127 4D96 19862 UInt UInt
6438 L3 Input 4 Off 43479 170/128 4D97 19863 UInt UInt
6439 L3 Set Dly 0s 43480 170/129 4D98 19864 Long, 1=1s EInt
643A L3 Res Dly 0s 43481 170/130 4D99 19865 Long, 1=1s EInt
643B L3 Tmr Val 0s 43482 170/131 4D9A 19866 Long, 1=1s EInt
644 Logic 4 31096 121/240 2448 1096 UInt, 1=1 UInt
6441 L4 Expr ((1.2).3).4 43483 170/132 4D9B 19867 UInt UInt
6442 L4 Input 1 CA1 43484 170/133 4D9C 19868 UInt UInt
6443 L4 Op 1 & 43485 170/134 4D9D 19869 UInt UInt
6444 L4 Input 2 NOT1 43486 170/135 4D9E 19870 UInt UInt
6445 L4 Op 2 & 43487 170/136 4D9F 19871 UInt UInt
6446 L4 Input 3 Run 43488 170/137 4DA0 19872 UInt UInt
6447 L4 Op 3 . 43489 170/138 4DA1 19873 UInt UInt
6448 L4 Input 4 Off 43490 170/139 4DA2 19874 UInt UInt
6449 L4 Set Dly 0s 43491 170/140 4DA3 19875 Long, 1=1s EInt
644A L4 Res Dly 0s 43492 170/141 4DA4 19876 Long, 1=1s EInt
644B L4 Tmr Val 0s 43493 170/142 4DA5 19877 Long, 1=1s EInt
650 Timers [650]
651 Timer1
6511 Timer1 Trig Off 43600 170/249 4E10 19984 UInt UInt
6512 Timer1 Mode Off 43601 170/250 4E11 19985 UInt UInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
