Fig. 42 Mains and motor connections model 48-060 to
48-105, frame size D2 and model 69-033 to 69-058
frame size D2(69).
Fig. 43 Mains and motor connections model 48-142 to 48-
293 (frame sizes E2 and F2) (principle drawing).
Fig. 44 Mains and motor connections model 48-142 to 48-
293 (frame sizes E2 and F2) with the optional termi-
nals for DC-, DC+ and Brake (principle drawing).
Fig. 45 Mains and motor connections model 48-365-20
(frame size FA2) with the optional terminals for DC-,
DC+ and Brake (principle drawing).
