Empisal EES50 - Winding the Bobbin

1
0
Winding the bobbin
2
3
4
0
1
Place the thread and spool holder onto the spool pin.
For smaller spools of thread, place spool holder with
the small side next to the spool or use the small spool
holder.
2
Snap the thread into the thread guide .
1
2
2
2
3
Wind the thread contrary clockwise around the bobbin
winder tension discs.
3
4
Place the thread end through one of the inner holes in
the bobbin as illustrated and place empty bobbin on the
spindle.
4
5
Push the bobbin to right.
5
