Empisal EES50 - Inserting the Bobbin

12
Inserting the bobbin
Attention:
Turn power switch to off ("O") before inserting
or removing the bobbin.
1
When inserting or removing the bobbin,
the needle must be fully raised.
Open the needle plate cover.
Insert the bobbin in the bobbin case with the
thread running in a counterclockwise
1
direction (arrow).
2
Pull the thread through the slit (A).
A
2
3
With a finger held gently on top of the
bobbin.
B
Draw the thread at the arrow markings into
the stitch plate thread guide from (A) to (B).
A
3
4
Pull the thread at the arrow markings into
B
the stitch plate thread guide from (B) to (C).
To cut off excess thread pull thread back
over the cutting off blade at point (C).
Close the needle plate cover.
C
4
