Figure 3: Module Label
The correspondence between article number and article code is shown in Table 3. The article code repre-
sents the product code, followed by the revision; the R suffix and number represent the revision number.
The revision changes and product known issues are described in the Mercury ZX1 SoC Module Known Issues
and Changes document [6].
Article Number Article Code
EN100644 ME-ZX1-30-2I-D10-R1
EN100645 ME-ZX1-35-1I-D10-R1
EN100646 ME-ZX1-45-2I-D10-P-R1
EN101075 ME-ZX1-30-2C-D10-R2
EN101076 ME-ZX1-30-2I-D10-R2
EN101077 ME-ZX1-35-1C-D10-R2
EN101078 ME-ZX1-35-1I-D10-R2
EN101079 ME-ZX1-45-2C-D10-P-R2
EN101080 ME-ZX1-45-2I-D10-P-R2
EN101723 ME-ZX1-30-2C-D10-R3
EN101724 ME-ZX1-30-2I-D10-R3
EN101725 ME-ZX1-35-1C-D10-R3
EN101726 ME-ZX1-35-1I-D10-R3
EN101727 ME-ZX1-45-2C-D10-P-R3
EN101728 ME-ZX1-45-2I-D10-P-R3
Table 3: Article Numbers and Article Codes
D-0000-403-002 12 / 56 Version 05, 25.07.2019
