MIO Pin Function
MIO15 MDIO select = 0 MDIO select = 1 (default)
MIO52 On-board I2C bus (I2C1.SCL) Ethernet PHY MDC
MIO53 On-board I2C bus (I2C1.SDA) Ethernet PHY MDIO
Table 10: Special MIO Pins
MIO Group Function Connection
0-14 QSPI and NAND flash QSPI/NAND flash
15 MDIO select/LED3# signal I2C/MDIO multiplexer selection, LED3#
16-27 Ethernet Gigabit Ethernet PHY
28-39 USB USB 2.0 OTG PHY
40-45 SD card/user functionality Module connector
46 UART RX
5
/user functionality
Module connector
47 UART TX
5
/user functionality
48-51 User functionality Module connector
Gigabit Ethernet PHY/
52-53 Ethernet MDIO/I2C On-board I2C bus and module connector
via level shifter
Table 11: MIO Pins Connections Overview
2.10 Multi-Gigabit Transceiver (MGT)
On the Mercury ZX1 SoC modules equipped with bigger SoC devices, there are eight Multi-Gigabit transceivers
and four reference input clock differential pairs available on the module connector B.
On the Mercury ZX1 SoC modules equipped with smaller SoC devices, there are only four Multi-Gigabit
transceivers and two reference input clock differential pairs available. Instead, on these modules, there are
additional regular I/Os routed to the module connector. Please refer to Section 2.9.2 for details on the MGT
connections for different SoC devices.
Table 12 lists the available speeds for the MGT lines on the SoC device. Refer to Section 2.2 for details on
the module configurations and equipped SoC devices.
5
UART RX is an SoC input; UART TX is an SoC output.
D-0000-403-002 23 / 56 Version 05, 25.07.2019
