MGT Speed SoC Device
4 MGTs @ 6.6 Gbit/sec Zynq-7030
8 MGTs @ 6.6 Gbit/sec Zynq-7035
8 MGTs @ 10.3125 Gbit/sec Zynq-7045
Table 12: MGT Switching Characteristics on the Mercury ZX1 SoC module
Warning!
The maximum data rate on the MGT lines on the Mercury ZX1 SoC module depends on the routing
path for these signals. Adequate signal integrity over the full signal path must be ensured when using
MGTs at high performance rates.
Warning!
No AC coupling capacitors are placed on the Mercury ZX1 SoC module on the MGT lines - make sure
capacitors are mounted, if required, on the base board (close to the module pins), to prevent MGT lines
from being damaged.
2.11 Power
2.11.1 Power Generation Overview
The Mercury ZX1 SoC module uses a 5 - 15 V DC power input for generating the on-board supply voltages
(1.0 V, 1.2 V, 1.35 V/1.5 V, 1.55 V, 1.8 V, 2.0 V, 2.5 V, 2.9 V and 3.3 V). Some of these voltages (1.8 V, 2.5 V, 3.3
V) are accessible on the module connector.
Table 13 describes the power supplies generated on the module.
D-0000-403-002 24 / 56 Version 05, 25.07.2019
