Module Product Family Reserved Revision Product Information
Mercury ZX1 SoC module 0x0327 0x[XX] 0x[YY] 0x0327 [XX][YY]
Table 43: Product Information
Module Configuration
Addr. Bits Comment Min. Value Max. Value Comment
0x08
7-4 SoC type 0 2
See SoC type
table (Table 45)
3-0 SoC device speed grade 1 3
0x09
7 Temperature range 0 (Commercial) 1 (Industrial)
6 Power grade 0 (Normal) 1 (Low power)
5-4 Gigabit Ethernet port count 0 1
3-2 Fast Ethernet port count 0 2
1 RTC equipped 0 1
0 Reserved - -
0x0A
7-2 Reserved - -
1-0 USB 2.0 port count 0 1
0x0B
7-4 DDR3 RAM (PS) size (MB) 0 (0 MB) 8 (1 GB) Resolution = 8 MB
3-0 DDR3 RAM (PL) size (MB) 0 (0 MB) 6 (256 MB) Resolution = 8 MB
0x0C
7-4 QSPI flash memory size (MB) 0 (0 MB) 7 (64 MB) Resolution = 1 MB
3-0 NAND flash memory size (MB) 0 (0 MB) 7 (512 MB) Resolution = 8 MB
Table 44: Module Configuration
The memory sizes are defined as Resolution×2
(Value-1)
(e.g. DRAM=0: not equipped, DRAM=1: 8 MB,
DRAM=2: 16 MB, DRAM=3: 32 MB, etc).
Table 45 shows the available SoC types.
Value SoC Device Type
0 XC7Z030, FBG package
1 XC7Z035, FBG package
2 XC7Z045, FFG package
Table 45: SoC Device Types
D-0000-403-002 49 / 56 Version 05, 25.07.2019
