5.2 Recommended Operating Conditions
Table 47 indicates the recommended operating conditions for Mercury ZX1 SoC module. The values given
are for reference only; for details please refer to the Zynq-7000 DC and AC Switching Characteristics Datasheet
[23].
Symbol Description Rating Unit
VCC_MOD Supply voltage relative to GND 4.75 to 15.75 V
VCC_BAT Supply voltage for the RTC and encryption key storage 2.0 to 3.45 V
VCC_IO_[x]
Output drivers supply voltage relative to GND Refer to Section 2.9.6 V
VCC_CFG_[x]
V_IO I/O input voltage relative to GND -0.2 to V
CCO
+0.2 V
Temperature
Temperature range for commercial modules (C)
*
0 to +70
◦
C
Temperature range for industrial modules (I)
*
-40 to +85
◦
C
Table 47: Recommended Operating Conditions
Warning!
*
The components used on the hardware are specified for the relevant temperature range. The user
must provide adequate cooling in order to keep the temperature of the components within the specified
range.
D-0000-403-002 52 / 56 Version 05, 25.07.2019
