PROline Prosonic Flow 93 PROFIBUS-DP/-PA 9 Trouble-shooting
Endress+Hauser 123
9 Trouble-shooting
9.1 Trouble-shooting instructions
Always start trouble-shooting with the checklist below, if faults occur after start-up or
during operation. The routine takes you directly to the cause of the problem and the
appropriate remedial measures.
"
Caution!
In the event of a serious fault, a flowmeter might have to be returned to the manufacturer
for repair. The procedures on Page 8 must be carried out before you return a flowmeter
to Endress+Hauser.
Always enclose a duly completed “Declaration of contamination” form. You will find a
preprinted form at the back of this manual.
Check the display
No display visible and no
output signals present.
1. Check supply voltage  Terminal 1, 2 (Page 49)
2. Check device fuse
Page 140
85...260 V AC: 0.8 A slow-blow / 250 V
20...55 V AC and 16...62 V DC: 2 A slow-blow / 250 V
3. Measuring electronics defective
 Order spare partPage 136
No display visible, but
output signals are present.
1. Check whether the ribbon-cable connector of the display module is
correctly plugged into the amplifier board
Page 138
2. Display module defective
 Order spare partPage 136
3. Measuring electronics defective
 Order spare partPage 136
Display texts are in a foreign
language.
Switch off power supply. Press and hold down both the
+/
 keys and switch on the measuring device again. The display text will
appear in English (default) and is displayed at maximum contrast.
▼
Error messages on display
Errors which occur during commissioning or measuring operation are displayed immediately.
Error messages consist of a variety of icons. The meanings of these icons are as follows (example):
– Error type: S = System error, P = Process error
– Error message type:
$ = Fault message, ! = Notice message
– S.VELOC RANGE = Error designation (e.g. sound velocity outside measuring range)
– 03:00:05 = Duration of error occurrence (in hours / minutes / seconds)
– # 491 = Error number
" Caution!
• See the information on Page 61 ff.!
• The measuring system interprets simulations and positive zero return as system errors, but displays
them as notice messages only.
Error number:
No. 001 – 399
No. 501 – 699
System error (device error) has occurred
Page 125 ff.
Error number:
No. 400 – 499
No. 700 – 799
Process error (application error) has occurred
Page 125 ff.
▼
