PROline Prosonic Flow 93 PROFIBUS-DP/-PA 10 Technical data
Endress+Hauser 145
10.1.5 Power supply
Electrical connection see Page 48 ff.
Supply voltage Transmitter:
85...260 V AC, 45...65 Hz
20...55 V AC, 45...65 Hz
16...62 V DC
Measuring sensors:
powered by the transmitter
Potential equalisation
For potential equalisation no special measures are necessary.
For instruments for use in hazardous areas, observe the corresponding guidelines in
the specific Ex documentation.
Cable entry Power supply and signal cables (inputs/outputs):
Cable entry M20 x 1.5 or
Cable gland for cables with Ø 6...12 mm
Threaded adapter 1/2" NPT, G 1/2"
Sensor cable connection (see Fig. 48 on Page 46):
A special cable gland allows you to insert both sensor cables (per channel) into the con-
nection compartment simultaneously.
Cable gland M20 x 1.5 for 2 x Ø 4 mm or
Threaded adapter 1/2" NPT, G 1/2"
Cable specification
Sensor cablePage 47
PROFIBUSPage 41
Power consumption AC: <18 VA (incl. sensor)
DC: <10 W (incl. sensor)
Switch-on current:
Max. 13.5 A (< 50 ms) at 24 V DC
Max. 3 A (< 5 ms) at 260 V AC
Power supply failure Lasting min. 1 cycle frequency:
EEPROM or T-DAT save measuring system data if power supply fails.
