PROline Prosonic Flow 93 PROFIBUS-DP/-PA 6 Commissioning
Endress+Hauser 97
Prosonic Flow 93 supports the following GSD files:
Each device is assigned an identification number by the Profibus User Organisation
(PNO). The name of the Device Master File (GSD) is derived from this.
At Endress+Hauser, this ID No. starts with the manufacturer ID 15xx.
In order to ensure clarity and make assignment easier, the GSD names (with the
exception of type files) at Endress+Hauser are as follows:
The GSD files for all Endress+Hauser devices can be acquired in the following manner:
 Internet (Endress+Hauser)  http://www.endress.com (Products  Process
Solutions
 PROFIBUS  GSD files)
 Internet (PNO)  http://www.profibus.com (GSD library)
 On CD-ROM from Endress+Hauser: order number 56003894
Structure of GSD files from Endress+Hauser
In the case of the Endress+Hauser field devices with PROFIBUS interface, all the files
which are needed for configuration are contained in one file. Once unpacked, the file
will create the following structure:
 Version #xx stands for the corresponding device version. Device-specific bitmaps
can be found in the directories “BMP” and “DIB”. The utilisation of these will depend
on the configuration software that is being used.
 The GSD files are saved in the subdirectories “Extended” and “Standard” which can
be found in the “GSD” folder. Information relating to the implementation of the field
transmitter and any dependencies in the device software can be found in the “Info”
folder. Please read this carefully before configuration takes place. The files with the
extension *.200 have been saved in the “TypDat” folder.
Name of device Manufacturer-specific
ID No.
Profile 3.0 ID No. Manufacturer-specific
GSD
Prosonic Flow 93 PA
PROFIBUS-PA
(IEC 61158-2 (MBP))
1530 (Hex) 9741 (Hex) EH3_1530.gsd
EH3X1530.gsd
Profile 3.0 GSD Type file Bitmaps
PA139741.gsd EH_1530.200 EH_1530_d.bmp/.dib
EH_1530_n.bmp/.dib
EH_1530_s.bmp/.dib
Manufacturer-specific
ID No.
Profile 3.0 ID No. Manufacturer-specific
GSD
Prosonic Flow 93 DP
PROFIBUS-DP
(RS 485)
1531 (Hex) 9741 (Hex) EH3_1531.gsd
EH3X1531.gsd
Profile 3.0 GSD Type file Bitmaps
PA039741.gsd EH_1531.200 EH_1531_d.bmp/.dib
EH_1531_n.bmp/.dib
EH_1531_s.bmp/.dib
EH3_15xx EH = Endress + Hauser
3 = Profile 3.0
_ = Standard identification
15xx = ID No.
EH3x15xx EH = Endress + Hauser
3 = Profile 3.0
x = Extended identification
15xx = ID No.
