AV : MD/ME - Rev. A Models
Installaon and Operaons Manual
PEX OR COPPER
TUBING
INDOOR
MODULE
OUTDOOR
UNIT
STAINLESS STEEL
FLEX TUBING KIT
NOT SHOWN:
PIPING INSULATION
NOT SHOWN:
OPTIONAL SUPPORT
STAND FOR AREAS WITH
SNOW ACCUMULATION
SUGGESTED
12” OFF FLOOR
MANUAL
AIR VENT
OUTSIDE
WALL
Pipe Sleeve
Foundation or Wall
Piping To/From
Outdoor Unit
End of Pipe Sleeve Must Be
a Minimum of 1” Beyond Wall
Fernco Fitting
⚠ NOTICE ⚠
SLEEVE MUST BE PROPERLY SEALED AT THE
WALL PENETRATION TO PREVENT LEAKS. THE
FERNCO FITTING MAY BE USED ON ONE OR
BOTH SIDES OF THE WALL. THIS IS JUST ONE
EXAMPLE OF ENSURING THAT THE EXPANSION/
CONTRACTION OF THE PIPING DOES NOT
ADVERSELY AFFECT THE WALL INTEGRITY.

HYDROSTATIC SEALS ARE ACCEPTABLE, AS WELL.
Piping Between Outdoor Unit and Indoor Module
Secon 4: Outdoor Installaon Consideraons
