Enertech AV Series - Flushing Diagram - Distribution Zones

Enertech Global, LLC 32
AV : MD/ME - Rev. A Models
Installaon and Operaons Manual

Secon 5: Unit Piping
RADIANT
FLOOR
HEATING
ZONE 2
RADIANT
FLOOR
HEATING
ZONE 3
DHW OUT
LOAD OUT
DOMESTIC
HOT
WATER
DOMESTIC
COLD
WATER
HOT
COLD
LOAD
IN
LOAD
OUT
LOAD IN
DHW IN
*FLUSHING CART
(USE AGFP DOUBLE 0-RING
x CAM ADAPTERS)
FLUSH BLOCKS
VALVE “OFF” THE
BOTTOM PORT
BYPASS VALVE
SET TO 4.5 PSI
HYDRONIC AIR HANDLER
OR PANEL RADIATIOR
ZONE 1
TURBOMAX 65
WATER HEATER
FOR TYPICAL
RESIDENTIAL
APPLICATIONS
MAKE-UP WATER OR
GLYCOL FEEDER
*FLUSHING BUCKET
(USE AGAMGH DOUBLE 0-RING x
MALE GARDEN HOSE ADAPTERS)
OAD O
AD IN
