Enertech AV Series - WPD Tables

Enertech Global, LLC 59
AV : MD/ME - Rev. A Models
Installaon and Operaons Manual
Secon 9: Equipment Start-Up
WPD Tables
PSI FTHD PSI FTHD PSI FTHD PSI FTHD
3.5 0.8 1.8 0.7 1.5 0.5 1.1 0.4 1.0
4.0 0.9 2.1 0.8 1.8 0.6 1.4 0.6 1.4
5.0 1.2 2.8 1.1 2.4 0.9 2.0 0.8 2.0
6.0 1.5 3.6 1.4 3.1 1.4 3.1 1.1 2.5
7.0 2.0 4.6 1.7 4.0 1.6 3.6 1.5 3.4
8.0 2.4 5.6 2.1 4.9 2.0 4.5 1.9 4.3
9.0 3.0 6.8 2.6 6.0 2.4 5.6 2.3 5.3
10.0 3.5 8.1 3.1 7.2 2.9 6.7 2.8 6.4
8.0 2.4 5.6 2.1 4.9 2.0 4.5 1.9 4.3
9.0 3.0 6.8 2.6 6.0 2.4 5.6 2.3 5.3
10.0 3.5 8.1 3.1 7.2 2.9 6.7 2.8 6.4
11.0 4.2 9.6 3.7 8.6 3.5 8.1 3.3 7.7
12.0 4.8 11.1 4.3 10.0 4.1 9.4 3.9 9.0
14.0 6.3 14.5 5.7 13.1 5.4 12.4 5.2 12.0
15.0 7.1 16.5 6.5 14.9 6.1 14.1 5.9 13.6
16.0 8.0 18.4 7.2 16.7 6.9 15.9 6.6 15.1
2.Pressuredropdataaccuratewithin±25%.
3.Unittestisrunwithouthotwatergeneration.
4.Interpolationofunitpressuredropdataispermissible;extrapolationisnot.
5.Pressuredropdataisaresultoflabtestingandisnotrelatedtowarranty.
6.Duetovariationsininstallation,actualunitperformancemayvaryfromthetabulateddata.
1.LoadWPDdataarebasedon15%(byvolume)methanolsolutionwhiletheunitandthe
load‐sidepumpareoff.
AV030
AV060
Model
Load
GPM
LoadSidePressureDropwithAntifreeze
50°F 80°F 100°F 110°F
