Enertech Global, LLC 38
AV : MD/ME - Rev. A Models
Installaon and Operaons Manual
If the EME/EMD is congured with the Turbomax domesc hot
water tank. A thermistor is pre-installed in the tank well for
monitoring tank temperature.
DHW: Domesc hot water thermistor input
Wire the thermistor to the EME/EMD Indoor Module. Follow
the three steps below. Reference the thermistor manual
included with the tank.
Step 1: Remove front access panel
Step 2: Drill hole through snap bushing
Note: Take cauon to not damage any components behind
snap bushing.
Step 3: Insert cable through snap bushing
• Install BLACK wire on le lug
• Install WHITE wire on right lug
⚠ WARNING ⚠
THE AQUASTAT NEEDS TO BE SET BELOW THE LOAD
O
THE AQUASTAT IS SET ABOVE THE LOAD LEAVING
TEMPERATURE, THE SYSTEM MAY NOT BE ABLE TO
SATISFY THE DEMAND.
Secon 7: Field Wiring
To Next Page
