Enertech AV Series - Pipe Connections; Snow Protection

Enertech Global, LLC 19
AV : MD/ME - Rev. A Models
Installaon and Operaons Manual
Secon 4: Outdoor Installaon Consideraons

• Pipe installaon must be carried out in accordance with
current local and federal regulaons.
• The unit is not equipped with external shut o valves on
the load side; these must be installed to facilitate any
future servicing.
• The unit should be vented through the venng valve. This
is located on the load outlet leaving the unit and would be
used to bleed o excess air within the water lines. See the
illustraon.
• Be sure to use both of the supplied corrugated stainless
steel ex tubing, aaching them directly to the inlet and
outlet on the outdoor unit. These exible tubes act as
vibraon dampers. Be sure to t them so that an elbow is
created on both lines.
• When assembling the ex tubes to the unit be certain to
use a two wrench system of ghtening. One wrench used
to back up the staonary copper ng ,the other to turn
the corresponding end of the ex tube. Tighten by moving
the wrench on the ex tube.
• All of the outdoor tubing must be fully insulated. 1-5/8”
insulaon is included with the corrugated stainless steel
tubing kit .
1-5/8” Insulaon included with
Flex Tubing kit. 12 feet total.
24 Inches
1-1/4”
FIP Thread
1-1/4”
FIP Thread
LEK
Data
Serie.nr.
Art
.nr. 711453
OUT
IN
Backup Wrench
Required

If there is a risk of snow or ice falling from a roof, a protecve
roof or cover must be erected to protect the heat pump, pipes
and wiring.
Snow Stand (Available in 12” & 18” Models)
