Enertech AV Series - EAV Unit Refrigerant Circuit Layout

Enertech Global, LLC 8
AV : MD/ME - Rev. A Models
Installaon and Operaons Manual
LEK
Compressor
(GQ10)
Refrigerant Circuit Labels
Solenoid Valve
EEV
Refrigeraon
Strainer
Connecon, Fluid
to Indoor Unit
Check Valve
Brazed Plate
Heat Exchanger
Reversing Valve
EEV, Subcooler
Connecon, Fluid from
Indoor Unit
Filter Drier
Fan
Compressor
Service Port,
Discharge Pressure
Service Port,
Sucon Pressure
EAV Unit Refrigerant Circuit Layout
Secon 2: Product & Unit Data
