Under sengs, scroll down to Pumps (advanced passcode
required).
• Load Pump Min Speed: This is the lowest % of PWM
signal the pump will run, regardless of Delta T seng.
3.6.0 3.6.1 Hot Water Setpoint 3.6.2 Hot Water Deadband
3.7.2 Load Pump Max Speed 3.7.3 Delta Temp Heat Setpoint 3.7.4 Deta Temp Cool Setpoint
3.8.1 Pressure Units 3.8.2 Replace Filter 3.9.0
3.7.0 3.7.1 Load Pump Min Speed
3.7.5 Temp Units 3.8.0
3.9.0.1 3.9.0.2
• Load Pump Max Speed: This is the highest % of PWM
signal the pump will run, regardless of Delta T seng.
• Delta Temp Cool Setpoint: This is the pump speed
that will maintain the Delta T (temperature dierence)
between entering and leaving uid temperatures. For
example, if the Delta Temp is set at 5 deg. F and the
entering temperature is 50 deg. F, the pump speed will
increase/decrease RPM to aempt to deliver 45 deg. F
leaving uid temperature to the system.
• Delta Temp Heat Setpoint: This is the pump speed
that will maintain the Delta T (temperature dierence)
between entering and leaving uid temperatures. For
example, if the Delta Temp is set at 8 deg. F and the
entering temperature is 90 deg. F, the pump speed will
increase/decrease spped to aempt to deliver 98 deg. F
leaving uid temperature to the system.
⚠ NOTICE ⚠
THE SYSTEM WILL ADJUST PUMP SPEED TO MAINTAIN
AT LEAST 4 GPM REGARDLESS OF DELTA T OR MIN. %
SETTING.
Secon 8: Controls

Under sengs, scroll down to Domesc Hot Water (advanced
passcode required).
• Hot Water Economy OFF: Electric immersion heat is used
under high demand situaons. Immersion heat is engaged
aer adjustable Aux HW Delay seng.
• Hot Water Economy ON: Compressor only hot water, no
electric immersion heat is used (not recommended).
3.1.1 Before Code 3.1.2 Before Code 3.1.0 Advanced Passcode
3.2.0 3.2.1 Heat Curve 3.3.0
3.4.1 Heat Min Temp 3.4.2 Heat Max Temp 3.4.3 Cool Setpoint
3.1.1 After Code (note: le name is 3.1.0.BMP) 3.1.1 Aux Heat Delay
3.3.1 Heat Setpoint 3.4.0
3.5.0 3.5.1 Aux HW Delay
• Hot Water Priority: See Indoor Climate.
• Hot Water Setpoint: Target tank temperature for DHW
operaon.
3.6.0 3.6.1 Hot Water Setpoint 3.6.2 Hot Water Deadband
3.7.2 Load Pump Max Speed 3.7.3 Delta Temp Heat Setpoint 3.7.4 Deta Temp Cool Setpoint
3.8.1 Pressure Units 3.8.2 Replace Filter 3.9.0
3.7.0 3.7.1 Load Pump Min Speed
3.7.5 Temp Units 3.8.0
3.9.0.1 3.9.0.2
• Hot Water Deadband: Temperature dierence from
setpoint to minimum temperature the tank can drop to
before heat pump is engaged.
⚠ NOTICE ⚠

ARE AVAILABLE WHEN THE ADVANCED PASSCODE
IS ENTERED. IT IS NOT RECOMMENDED FOR
HOMEOWNERS/BUILDING OWNERS ENTER THIS MODE
WITHOUT A QUALIFIED TECHNICIAN ON SITE.
THE PASSCODE IS 001.
