Enertech AV Series - Thermistor Legend

Enertech Global, LLC 66
AV : MD/ME - Rev. A Models
Installaon and Operaons Manual
Type 1 Thermistor Type 2 Thermistor Type 3 Thermistor
Deg F k Ohms Deg F k Ohms Deg F k Ohms
-25 202 -25 27 -25 5283
-20 171 -20 24 -20 4441
-15 144 -15 21 -15 3724
-10 121 -10 18 -10 3121
-5 102 -5 16 -5 2617
0 87 0 14 0 2202
5 74 5 12 5 1863
10 63 10 10 10 1586
15 55 15 9.2 15 1361
20 47 20 8.1 20 1173
25 41 25 7.2 25 1012
30 35 30 6.3 30 864
35 30 35 5.5 35 717
40 26 40 5.0 40 636
45 23 45 4.4 45 553
50 20 50 3.9 50 480
55 18 55 3.5 55 417
60 15 60 3.1 60 363
65 13 65 2.8 65 316
70 12 70 2.5 70 276
75 10 75 2.3 75 243
80 9.3 80 2.1 80 214
85 8.3 85 1.9 85 189
90 7.4 90 1.7 90 168
95 6.6 95 1.5 95 149
100 5.8 100 1.4 100 131
105 5.1 105 1.2 105 114
110 4.6 110 1.1 110 101
115 4.2 115 1.0 115 92
120 3.8 120 0.95 120 83
125 3.4 125 0.87 125 74
130 3.1 130 0.80 130 67
135 2.8 135 0.73 135 60
140 2.5 140 0.67 140 54
145 2.3 145 0.61 145 48
150 2.0 150 0.56 150 43
155 1.8 155 0.51 155 38
160 1.7 160 0.47 160 34
165 1.5 165 0.43 165 31
170 1.4 170 0.40 170 28
175 1.2 175 0.37 175 25
180 1.1 180 0.34 180 23
185 1.0 185 0.31 185 21
190 0.95 190 0.29 190 19
195 0.87 195 0.27 195 17
200 0.81 200 0.25 200 16
205 0.75 205 0.24 205 15
210 0.70 210 0.22 210 14
215 0.66 215 0.21 215 13
220 0.62 220 0.20 220 12
225 0.58 225 0.19 225 11
230 0.54 230 0.17 230 10
235 0.50 235 0.16 235 9.6
240 0.46 240 0.15 240 8.7
245 0.41 245 0.14 245 7.6
250 0.35 250 0.13 250 6.5
255 0.29 255 0.11 255 5.1
260 0.23 260 0.10 260 3.5
Thermistor Legend
Type Locaon
1
 There
are 4 thermistors on the
Outdoor unit, Load In (BT3),
Load Out (BT12), Liquid line
(Heang) (BT15), and Vap
Injecon (BT81). There are 2
thermistors in the Indoor unit,
Load In and Load out. There
is 1 thermistor located in the
Turbo Max storage tank.
2
Blue 6K Thermistors: There
are 4 thermistors on the Out-
door unit, Liquid Line (Cooling)
(BT16), Outdoor Air (BT28),
Sucon Line (BT17), and Suc-
on - Evap (Heang) (BT84).
3
Red 5.374K Thermistor:
Compressor Discharge Temp
(BT14).
Secon 10: Troubleshoong
