Installing and Connecting B5 Redundant Power Systems
2-12 Installation
Unpacking the Shelf and Power Supply
Theshelfandthepowersupplyareshippedseparately.Tounpackthesedevicesproceedas
follows:
1. Opentheboxandremovethepackingmaterialprotectingtheshelforpowersupply.
2. Verifythecontentsofeachcartonandcomparethecontentsshippedwiththoselistedin
Table 2‐1,Table 2‐2,andTable 2
‐3.
3. Performavisualinspectionoftheswitchdevicesforanysignsofphysicaldamage.Contact
Enterasys Networksifthereareanysignsofdamage.Referto“GettingHelp”onpage xviifor
details.
Installing an STK-RPS-150PS
WhenyoureceiveyourSTK‐RPS‐150CH2orSTK‐RPS‐150CH8shelf,acoverplatewillbeinplace
overeachpowe r‐supplyslot.
Toinstallthepowersupplies,refertoFigure 2‐7orFigure 2‐8andproceedasfollows:
1. Placethechassisonasturdyflatsurfacewhereyouplanto
installpowersupplies.
2. Alignthepowersupplywithoneoftheslots,thenslidethepowersupplyforwarduntilits
frontpanelisflushagainstthechassisfrontpanel.
Table 2-1 Contents of STK-RPS-150CH2 Carton
Item Quantity
STK-RPS-150CH2 1
Quick Reference 1
Release Notes 1
Table 2-2 Contents of STK-RPS-150CH8 Carton
Item Quantity
STK-RPS-150CH8 1
Quick Reference 1
Release Notes 1
Table 2-3 Contents of STK-RPS-150PS Carton
Item Quantity
STK-RPS-150PS 150 watt DC power supply 1
USA, NEMA power cord 1
RPS cable 1
Notice card 1
Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic
equipment.
Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precauciones de
seguridad para evitar descargas de electricidad estática.
Note: To prevent EMI leakage from the shelf, keep coverplates installed over any empty power
supply slots.
